QUEST 2135 INST 12 97 2135 Microwave PIR Intrusion Detector Power to 15 VDC 16 mA DC nominal up to 48 mA DC during testing or trouble conditions Power Relay internal standby battery Connect to DC power sources of supplying standby power Sixteen mA H re for each hour of standby time needed operating Normally Closed reed relay Contacts rated watts 125 mA 28 VDC maximum for DC resistive loads protected by a 4.7 ohm 1 2 watt resistor in the com leg of the relay Do not use with capacitive or loads Ghz 25 MHz ft by 35 ft 10.7 m by 10.7 m Closed with cover on Contacts rated at 28 VDC A max Connect tamper circuit to 24 hour protection SB2 swivel bracket Use of a bracket may re range and dead zone area protected coverage area is where the microwave and PIR overlap use the optional Look Down Zone the Mask must be removed the Look Down Lens Use caution to remove the black only Do not attempt to remove the white lens assembly not remove the Mask for pet applications See Figure 2 Hints Never install the detector in an environment that causes an alarm condi in one technology Good installations start with the LED OFF when is no target motion It should never be left to operate with the tri LED in a constant or intermittent green yellow or red condition Point the unit away from outside traffic roads alleys Remember Mi energy will pass through glass and most common non metallic walls Avoid installations where rotating machines e g ceil fans are normally in operation within the coverage pattern Point the unit away from glass exposed to the outdoors and objects that change temperature rapidly Remember The PIR detector will to objects rapidly changing temperature within its field of view Eliminate interference from nearby outside sources Instructions Installations Containing Pets QUEST 2135 will provide reasonable protection from nuisance caused by the following sources A dog up to 100 pounds Two dogs up to 60 pounds each Up to 10 cats take full advantage of the QUEST 2135 Pet Exclusion Technology following guidelines should be followed Mount the center of the detector 6 1 2 feet high and adjust the vertical to 5 Mount where animals cannot come within six feet of the detector by on furniture boxes or other objects Do not aim the detector at stairways that can be climbed by an animal Adjust the microwave range for the minimum acceptable coverage for room in which the detector is installed Never install with the micro range exceeding 35 feet nuisance protection has not been verified by Underwriter Inc to 120 40 to 49 For U L Listed Require the temperature range is 32 to 120 0 to Multiple small rodents such as rats Random flying birds to Vertical Horizontal Set the PIR sensitivity for standard STD 1 Coverage Pattern 2 Interior View Select a location likely to intercept an intruder moving across the cover pattern The surface should be solid and vibration free Mounting range is six to eight ft 1.8 to 2.4 m Recommended mounting is 6 1 2 ft 2 m Remove the cover Insert a flathead screwdriver into the locking tab hole the bottom front of the detector Pull the cover up and forward Remove the circuit board from the base Loosen the Vertical Adjustment and slide the circuit board down then out Using the base as a template mark the location of the holes on the mount surface Route wiring unpowered as necessary Route to the rear of the base through the wire entrance Firmly mount the base to the mounting surface Return the circuit board the base and tighten the Vertical Adjust Screw power after all connections have been made and Do not coil excess wiring inside the detector Terminals 1 2 Power are 9 to 15VDC Use no than 22 AWG wire pair feet 150m max between detector and the power Terminals 3 4 Alarm relay contacts rated at 3 watts amps 28VDC maximum DC resistive loads and pro by a 4.7 ohm 1 2 watt the detector experiences a Microwave or PIR self test failure four pulse it is in need of replacement walk testing the LED will light for the first technology microwave PIR and then light red to indicate a detector alarm The LED will not activation of the second technology by lighting its color 2 Selection On Off pins The ON allows operation of the LED If the tri color indication is not desired the setup and walk tests been completed place plug in the OFF position OFF position does not prevent the tri color LED from a supervision trouble condition Sensitivity Selection Pins Selection of the PIR response sensitiv may be selected by placing the plug across the pins marked STD for or INT for intermediate mode Sensitivity The recommended setting for maximum false alarm It tolerates environment extremes on this setting This setting required for pet avoidance Sensitivity The recommended setting for any location where intruder is expected to cover only a small portion of the protected area tolerates normal environments on this setting This setting will improve intruder catch performance Intermediate Sensitivity is not for installations containing pets the vertical starting angle from the chart below and Walk Tests the vertical starting for the desired mounting and range proper vertical must be for pets unit has stabilized and has seen no movement for two approximately one to two minutes When the LED flashing the detector is ready to be tested With no motion the protection area the LED should be OFF If the LED is on the protection area for disturbances affecting the yellow or PIR green technologies PIR Pattern Coverage Turn the Microwave range adjust to minimum Walk test across the pattern at its farthest edge then several times to the detector Start walking from outside of the intended protec area and observe the tri color LED The edge of the pattern is deter by the first green PIR activation of the LED or the first red activa if the yellow microwave LED activates first Walk test from the opposite direction to determine both boundaries The of the pattern should be pointed toward the center of the intended area Slowly bring your arm up and into the pattern to mark the lower boundary PIR alarm Perform this task at 10 to 20 ft 3.1 to 6.1 m from the unit from above for the upper boundary The center of the pattern not be tilted upward desired coverage can not be achieved try angling the coverage pattern or down to assure the pattern is not aimed too high or low For pet do not adjust below recommended angle Do not use with capacitive or inductive loads Terminals 5 8 Spare Terminals 6 7 Tamper contacts rated at 28VDC 0.125A Place the LED plug in the ON position and replace the cover Wait at least two minutes after applying power before starting walk Plug the wire entrance hole with the foam plug provided During the warm up period the tri color LED will flash red until Operation detector uses a tri color LED to indicate the various alarm and troubles that may exist See chart below angle of the PIR pattern may be vertically positioned between and 2 by loosening the Vertical Adjust screw and sliding the board up or down Moving the board up will angle the pattern Tighten the screw snug when positioning is completed pattern may be moved horizontally by moving the lens the left or right Microwave Coverage is important to wait one minute after removing replacing the so the microwave portion of the detector can settle and to at least 10 seconds between the following walk testing The tri color LED should be OFF before walk testing Walk test across the pattern at the intended coverage farthest end walking from outside the intended protection area and observe the
