Ademco - Vista 20SEa Installation Addendum (Australian)

ADDENDUM TO VISTA 20SEa INSTALLATION INSTRUCTIONS with Issues N8145V1 dated 10 98 Code code 16 is a global Duress code Entering this code at a console will generate a Contact ID code of 121 with user 92 If the system is programmed for Open Close reports it will also an Open Close report by user 16 to the central station Bell Siren Output alarm output may be supervised by cutting the red jumper located above terminals 1 and 2 see 1 and by connecting a 2K ohm resistor at the bell siren A short or open in the alarm output will result in a Check Trouble display and a Contact ID event code of 321 to be sent to the station of Arming Ding Options additional option for sounding the bell siren when the system is armed with a RF button is now for either or both partitions Program a 2 in field S 38 to enable this feature Smoke Detectors smoke detectors should be powered from the Programmable Trigger Output Pin 7 and Pin of the 9 pin connector located near the middle of the circuit board see figure 1 Program a 2 in S 90 to enable the trigger output for Resettable Smoke Detector Power Jam Detection 5882 RF receiver supports RF Jam Detection If a continuous RF transmission of greater than seconds is detected the system will generate a RF Jam display and a Contact ID event code of will be sent to the central station Program a 4 in field S 22 to enable this feature Output the negative of the strobe to Pin 8 of the 9 pin connector located near the middle of the board see Figure 1 Connect the positive of the strobe to terminal 5 of the main terminal programming is required for the Strobe function PIN HEADER HEATSINK JUMPER 20 SEa MAIN TERMINAL 1 4 Wire Smoke Detector and Strobe Connections DEVICE MANUFACTURING CO DIVISION OF PITTWAY CORPORATION Australia Pty Ltd 5 Riverside Centre 24 28 River Road West NSW 2150 Australia 1999 PITTWAY CORPORATION 10 99
