Andover Controls Continuum Enclosure and Display Module System

NEMA 1 Style Enclosure for Installation of Continuum Intelligent System Built in DIN Rails for Easy Mounting of CPU Power and up to 10 I O Convienent Front Door of up to 9 Local Display Durable Steel Welded Built in Cable Management Streamline and Wiring Runs and Display Module System Continuum NEMA 1 style enclosure provides a convenient way to wall mount an Continuum intelligent building system in a single location and is uniquely styled match your Andover Controls Continuum product line The enclosure makes initial and future change outs of the Continuum modules quick and easy provides for technicians and protection from environmental elements and offers front door mounting of the Continuum LED and LCD local display modules MODULE INST MODULE INST MODULE INSTALLAALLAALLAALLAALLATIONTIONTIONTIONTION MODULE INST MODULE INST six inch deep enclosure provides room to mount the Continuum NetController CPU power supply and up to ten modules on three built in DIN rails The DIN rails are attached to a removable steel back plate which allows to mount the actual enclosure separately from the Continuum modules Simply hook each module onto the DIN plug the built in power communications connector on the left side of each module into the complimentary on the right side of the previous module and then snap close the quick release fasteners to lock the in place on the rail It that easy I O modules if needed can be located in additional Continuum enclosures In addition a single I O module or of I O modules can be located outside an enclosure for example to control a remote door or lighting system additional I O modules are connected to the Continuum system using approved cable and an external 24VDC supply DESIGN DESIGN DESIGN DESIGN DESIGN enclosure welded design and rugged cold rolled steel construction ensure durability Vertical support bars on inside of the cabinet door provide added rigidity and a built in door lock guards against tampering Cable troughs underneath each DIN rail streamline and protect wiring runs A bracket for two 12V 7.0 AHr rechargeable batteries is provided at the bottom of the enclosure for UPS support DOOR DISPLAY AND CONTROL MODULES DOOR DISPLAY AND CONTROL MODULES DOOR DISPLAY AND CONTROL MODULES DOOR DISPLAY AND CONTROL MODULES DOOR DISPLAY AND CONTROL MODULES front door of the enclosure contains removable sections into which the Continuum display and control modules be mounted These modules LB 8 LED Bar Module LS 8 LED 3 Digit Module LC 1 2 Line Display with VM 1 Voice Module and the GA 40 80 Graphic Annunciator Panels secured directly into the back of door with screws and connected to the I O bus by a five conductor cable assembly The Continuum system treats these display modules as additional I O modules Up to nine display modules can be mounted on the Mix various combinations of display modules to meet your specific operator interface needs Alternately the can be ordered with only three tinted Plexiglas panels in the door This option allows you to view the lights of all internal modules when the enclosure door is closed Manuals Online LED BAR MODULE LED BAR MODULE LED BAR MODULE LED BAR MODULE LED BAR MODULE 8 user programmable LED ON OFF indicators 8 user programmable push button digital inputs LB 8 LED Bar Module provides a cost effective way to view and modify your facility operation with 8 programmable LED each with its own programmable companion push button with audible feedback The LB 8 is an excellent choice for equipment status indication ON OFF control and override capability Programming the LED indicators and push buttons is with Andover Controls Plain English programming language Labels above each LED and companion push button allow you customize each I O point LED 3 DIGIT DISPLAY MODULE LED 3 DIGIT DISPLAY MODULE LED 3 DIGIT DISPLAY MODULE LED 3 DIGIT DISPLAY MODULE LED 3 DIGIT DISPLAY MODULE 8 user programmable 3 digit 7 segment LED displays with floating decimal point 8 user programmable up down arrow push button digital inputs LS 8 LED 3 Digit Display Module combines eight 3 digit 7 segment LED displays with 8 companion up down arrow push Use the LEDs to display building parameters such as temperature airflow humidity or occupancy status The up down push buttons with audible feedback allow an operator to turn equipment on and off change set points air balance VAV adjust override time arm and disarm a security system etc Programming the LED displays and up down push buttons is with Andover Controls Plain English programming language Labels above each LED and companion push button allow you customize each I O point 2 LINE DISPLAY 2 LINE DISPLAY 2 LINE DISPLAY 2 LINE DISPLAY 2 LINE DISPLAY 16 character by 2 line LCD display with backlighting 12 button programmable keypad Optional VM 1 Voice Module Similar functionality to Infinity Infistat Display Interface LC 1 Display Module features a 16 character by 2 line LCD display with backlighting and a 12 button ergonomically designed keypad left right arrows for LCD cursor control Enter and Cancel push buttons and 6 user functions keys With one touch of a finger you can scroll through building parameters such as temperatures or view equipment status change setpoints and schedules turn equipment on and off or air balance VAV boxes The can also be programmed to perform a wide variety of functions including switching a specific zone to occupied mode an alarm condition adjusting the amount of override time arming and disarming a security system and enforcing security Programming the display and function keys is done with Andover Controls Plain English programming A label window above the six functions keys is provided LC 1 interfaces to the optional VM 1 Voice Module Manuals Online VOICE MODULE VOICE MODULE VOICE MODULE VOICE MODULE VOICE MODULE Voice record and playback On board speaker Microphone input Audio output jack VM 1 Voice Module provides local voice annunciation for your Continuum system Operators can record and store 100 custom messages 2 minutes maximum total record time for playback Use the VM 1 to annunciate alarm provide audible instructions for critical applications or broadcast messages over the building public address system a built in audio pre amp level output signal Pre recorded messages can also be played back as a result of an event occurrence a Plain English language program resident in the Continuum NetController VM 1 interfaces to the LC 1Display Module and mounts adjacent to it in the Continuum enclosure front door Record control is provided via the LC 1 keypad LCD display The VM 1 features an on board speaker with volume control 1 8 microphone input and a pre amp level output and a built in transitor for ON OFF control of the PA channel during message GRAPHIC ANNUNCIA GRAPHIC ANNUNCIA P P PANEL GRAPHIC ANNUNCIATOR P GRAPHIC ANNUNCIA P GRAPHIC ANNUNCIA Door mounted panel Graphically represents 40 or 80 I O points Built in interface to Continuum DM 20 modules Pre terminated LEDS and control switches provided Optional firefighter controls for smoke management applications Continuum GA 40 80 Graphic Annunciator Panel provides a convenient graphic representation of your building mechanical ventilation systems smoke control sequences or other panel applications The GA 40 80 includes a backplate holes for 40 80 status LEDs and control switches and mounts directly inside the door of the Continuum enclosure a graphic with predefined holes to the front of the door LEDS are available in three color choices red yellow green and switches are available in two lengths 0.5 and 1.0 and two styles flat blade and round Connectors for both the LEDS switches are provided and attach directly to the built in terminal blocks for interface to one or more Continuum DM 20 I O mounted on the enclosures DIN rail The GA 40 80 accepts 24VDC from the DM 20 via a three position cable assembly converts it to 5VDC Each DM 20 can provide power for up to 20 inputs or outputs T
