Autocall A4603-9101 LCD Annunciator for 4100ES Fire Alarm Control Panels

Datasheet Accessories LCD Annunciators LCD Annunciator for 4100ES Fire Alarm Control Panels 1 LCD Annunciator Controls Notification appliances can be deactivated by the ALARM SILENCE switch Exact operation is determined the host control panel such as visible appliances remaining on until is reset Pressing the SYSTEM RESET switch restores the to normal operation When system activity is normal the LCD the time date and SYSTEM IS NORMAL Switches Four programmable CONTROL switches and LEDs are included Typical applications include manual door holder release bypass and elevator capture bypass Enable All switches on the annunciator are controlled by ENABLE keyswitch with a key that is removable only in the disabled A brief lamp LCD test is performed whenever the keyswitch is from enabled to disabled Backup Operation During battery backup the LED is disabled to conserve battery power When an annunciator is activated the backlighting is automatically enabled After 30 seconds of inactivity the backlighting will again be ULC CSFM Listed FM LCD annunciator for use with Autocall model 4100ES fire alarm control panels display features Maintained display of first alarm is available with 4100ES at software 11.11 or higher Wide viewing angle super twist LCD technology with green LED Two lines of 40 characters each LED status indicators During battery backup backlighting is disabled until there is switch include Switches for system acknowledge alarm silence and system reset Four programmable control switches Lamp LCD test information RUI Remote Unit Interface communications require a single twisted pair see A4603 9101 LCD Annunciator Specifications for more Separate wiring is required for 24 VDC control panel power mount on standard electrical boxes 2975 9206 Surface mount box A4603 9111 Brushed stainless steel trim Listed to Standard 864 Control and Annunciation is provided using an 80 character alphanumeric display Information is presented in clear English language and includes Point Status alarm trouble Alarm Type smoke detector manual station etc Number of Alarms Supervisory Conditions and Trouble Conditions a Custom Location Label A single twisted wire pair provides serial RUI communications also supports other Autocall serial annunciators on the same wire Indications Alarm Supervisory and Trouble conditions are indicated by dedicated LEDs and a tone alert audible sounder Each has a dedicated acknowledge push button switch that silences tone alert but leaves the LED on until all conditions in that category restored to normal Switch operation is either globally or individually determined by the control panel operation operation of the appropriate acknowledge switch will scroll the display showing activity in the sequence of occurrence The tone also pulses to indicate the operation of any of the push button local code requirements for guidance in determining and location of the A4603 9101 LCD annunciator This product has been approved by the California State Fire Marshal CSFM pursuant to Section 13144.1 of the California Health and Safety Code See CSFM Listings 7120 2269 0546 7120 2269 0547 7300 2269 0567 for allowable values and or conditions concerning material presented in this document Additional listings may be applicable contact your local product supplier for the latest Rev 16 03 2021 Operator Information LCD Annunciator for 4100ES Fire Alarm Control Panels Information mount box model 2975 9206 2 Rev 16 03 2021 Reference LCD Annunciator for 4100ES Fire Alarm Control Panels 2 LCD Annunciators Notes Communications require a single 18 AWG twisted pair Power requires two 18 to 12 AWG wires for 24 VDC system power plus Earth Ground to each electrical box Refer to Installation Instructions 579 949AC for additional wiring specifications Selection LCD Annunciator with beige trim LCD Annunciator with beige trim with French keypad for Canada stainless steel trim option surface mount box ivory finish protector required where annunciator communications and power wiring exits and enters a building refer to data AC2081 0016 for details to A4603 9101 LCD Annunciator Specifications additional details LCD Annunciator Specifications additional information refer to Installation Instructions 579 979AC Operating Current Standby Current Current Temperature Range Humidity Range 1 General Operating Specifications to 32 VDC system supplied mA with LED backlighting on mA during battery backup LED backlighting is turned off after 30 seconds without switch activity mA maximum LED backlighting is on and tone alert is sounding to 120 F 0 to 49 C to 93 RH non condensing at 100 F 38 C 2 Communications Capacity Per RUI Remote Unit Interface external annunciator communications line SLC signaling line circuit to 31 remote annunciators MINIPLEX transponders per channel including the A4603 9101 LCD the A602 9101 Status Command Unit SCU and A602 9102 Remote Command Unit refer to data sheet AC4100 0031 for additional 4100ES information 3 Rev 16 03 2021 LCD Annunciator for 4100ES Fire Alarm Control Panels 3 Wiring Requirements Wiring Type Characteristics Data Applications Shielded Pair STP twisted pair UTP 18 AWG 0.82 mm2 for most applications see below 580 nF maximum capacitance between conductors 35 maximum total line resistance Wiring that leaves the building Also requires Isolated Loop Circuit Protectors on each end refer to data AC2081 0007 for A2081 9027 200 mA or S2081 0008 for A2081 9028 5 A Wiring run in 500 ft 152 m or more of conduit Wiring closely bundled with standard IDNet communications or TrueAlert addressable communications required when run with IDNet communications B T Tap wiring X wiring distance Wiring Wiring to 10,000 ft 3048 m total wiring up to 2500 ft 762 m to farthest device to 2500 ft 762 m to 12 AWG 0.82 mm2 to 3.31 mm2 wires for 24 VDC system power dedicated earth ground connection to the electrical box is required for proper ESD and EMI protection wire accordance with NFPA 70 National Electrical Code Article 250 General Conduit Entrance Requirement Dimensions Trim Finish Optional Trim for Flush Mounting supplied by others 4 Mounting Information entrance must be located a minimum of 2 70 mm from the front of the box to assembly H x 11 13 16 W 114 mm x 300 mm painted beige stainless steel ordered separately supplied with both slotted and tamper resistant 3 89 mm deep Steel City GW 635 G 6 gang masonry box RACO 590 gangable box 6 required or equal 5 2975 9206 Surface Mount Box Option ordered separately 31 32 W x 4 H x 2 D 304 mm x 117 mm x 70 mm steel ivory finish 2021 Johnson Controls All rights reserved All specifications and other information shown were current as of document revision and are subject to change without notice listings may be applicable contact your local Autocall product supplier for the latest status Listings and approvals under Tyco Fire Security GmbH and the names listed in this material are marks and or registered marks Unauthorized use is strictly prohibited NFPA 72 and National Fire Alarm Code are registered of the National Fire Protection Association NFPA Rev 16 03 2021
