Autocall Duct Detector Housings with TrueAlarm Photoelectric Detector for Stand-Alone Operation

UL ULC CSFM Listed Smoke Detectors Detector Housings with TrueAlarm Photoelectric Detector for Stand Alone Operation Operation an alarm is detected the on board relay contacts transfer the control tone alert sounds and the alarm LED illuminates Activating the switch will silence the tone alert After the source of the alarm is and resolved turning the key switch to Test Reset will reset the Relay Operation output relay contacts are held energized during normal operation loss of power or removal of the detector the contacts will transfer stand alone operation air duct detector housing with cover to monitor for the presence of smoke factory installed TrueAlarm photoelectric smoke and features On board TrueAlarm sensitivity drift compensation and dirt tracking Multi function status LED indicator on detector Magnetic test that initiates an alarm and provides detailed diagnostic Clear cover allows visual inspection Test ports provide functional smoke testing access with cover in place Input power of 120 VAC 24 VAC or 24 VDC UL listed to Standard 268A relay output features Fail safe operation that is normally energized and transfers upon loss of power or detector removal Contacts are Form C rated 5 A 120 VAC or 28 VDC resistive requires Control Station A4098 9842 Provides power on LED alarm LED local tone alert signal local tone silence and keyed test reset switch Control station is ordered separately to rectangular ducts or round ducts Minimum size is 8 203 mm square or 18 457 mm diameter operated functional test Initiates alarm and displays dirt accumulation status using the detector LED dirty detectors Assists with maintenance priorities by categorizing detector status and tubes ordered separately Available in multiple lengths to match duct size Installed and serviced with housing in place Please note that smoke detection in air ducts is intended to provide of the presence of smoke in the duct It is not intended to will not replace smoke detection requirements for open areas or non duct applications Operation A4098 9687 stand alone duct detector housings with smoke are for applications that operate independent of a fire alarm panel They provide a TrueAlarm smoke detector for monitoring conditioning or ventilating ducts Sampling tubes are installed into duct allowing air to be directed to the smoke detector mounted in housing Control Station A4098 9842 a red alarm LED a green power on LED a piezoelectric tone a tone alert silence switch and a key switch for selecting normal mode or to initiate a test or reset operation This control is required 1 Stand Alone Detector Housing Front View 2 Control Station This product has been approved by the California State Fire Marshal CSFM pursuant to Section 13144.1 of the California Health and Safety Code See CSFM Listings 3240 2269 0526 and for allowable values and or conditions concerning material presented in this document Additional listings may be applicable contact your local Autocall product supplier for the latest Rev 7 1 2020 Detector Housings with TrueAlarm Photoelectric Detector for Stand Alone Operation Detector Selection Chart operation duct detector with internal output relay input power is VAC 24 VAC or 24 VDC A4098 9842 Test Station ordered 1 Control Station required ordered separately Station with power on green LED red alarm LED tone alert silence and key switch for test reset on stainless steel plate double gang box 3 H x 4 W x 2 D 76 mm x mm x 51 mm Stand alone duct detector housing includes an internally mounted model A4098 9601 TrueAlarm photoelectric detector and an exhaust tube A sized sampling tube ordered per application is required refer to chart below Tube Selection Chart Ordered Separately Per Duct Width Select One Duct Width 305 mm to 23 330 mm to 584 mm to 46 610 mm to 1168 mm to 71 1168 mm to 1803 mm to 95 1803 mm to 2413 mm Cut Length 12.7 mm longer than duct width 12.7 mm longer than duct width in 76 mm longer than duct width in 76 mm longer than duct width in 76 mm longer than duct width Required Control Station Indicator Reference Status missing detector head power fail LED On Off Detector Status LED Indications Indication approximately every 4 seconds On 2 LED Indications LED Relay energized de energized 3 Detector LED Response to Magnetic Test Indication turns ON pulses quickly 6 times in 3 then turns ON pulses slowly 4 times in 8 then turns ON By is initiated is initiated is initiated not initiate Alarm sensitivity is within compensation sensitive out of normal range sensitive out of normal compensation is malfunctioning or other service is is required Testing requires placing a magnet at the designated location on the duct housing cover for 4 seconds and referring to the response from the red status indicator on the detector Refer to Installation Instructions 574 777AC for further test and maintenance information 2 Rev 7 1 2020 Duct Detector Location Reference Detector Housings with TrueAlarm Photoelectric Detector for Stand Alone Operation Information Refer to NFPA 90A Standard for the Installation of Air Conditioning and Ventilating Systems NFPA 72 the National Fire Alarm Signaling Code and the NEMA Guide for Proper Use of Smoke Detectors in Duct Applications and Installation Instructions 574 776AC Detector Location Considerations Proper duct smoke detection location must ensure adequate airflow within the duct housing Duct air velocity rating is 300 to 4000 ft min 91 to 1220 m min Pressure differential between intake and exhaust tubes is required to be 0.015 to 1.55 inches of water 0.381 to 39.37 mm Ensure accessibility for test and service Proper Locations downstream side of filters to detect fires in the filters in return ducts ahead of mixing areas upstream of air humidifier and coil Other locations and orientations may be required for proper duct smoke detection depending on duct access system design and duct airflow Contact your local Autocall product supplier for assistance to Avoid Where dampers closed for comfort control would interfere with airflow Next to outside air inlets unless the intent is to monitor smoke entry from that area return air damper branch ducts and mixing areas where airflow may be restricted 3 Rev 7 1 2020 Detector Housings with TrueAlarm Photoelectric Detector for Stand Alone Operation Selectable at Housing Range Current Current Rating Form C Contacts Specifications Velocity Range linear ft min Listed Temperature Range Temperature Range Temperature Range Range Color and Material and Exhaust Tube Material Connections Housing and Control Station Station A4098 9842 from Housing and Controls Requirements VAC 60 Hz to 132 VAC mA mA A resistive 120 VAC or 28 VDC VAC 60 Hz to 26.4 VAC mA mA VDC to 32 VDC mA mA to 4000 ft min 91 to 1220 m min to 100 F 0 to 38 C to 122 F 0 to 50 to 140 F 18 to 60 C to 95 RH non condensing ABS base with clear polycarbonate cover CPVC custom extrusion sampling tubes are pre drilled blocks 18 to 12 AWG 0.82 mm2 to 3.31 mm2 ft 152 m maximum power on LED red alarm LED local sounder silence toggle switch key switch select normal or test reset mode refer to table on page 2 for status indication list conductors 18 AWG typical wiring assume 25 mA maximum for conductor sizing 2020 Johnson Controls All rights reserved All specifications and other information shown were current as of document revision and are subject to change without notice listings may be applicable contact your local Autocall product supplier for the latest status Listings and app
