Autocall Non-Addressable Audible Visible Notification Appliances for 4-Wire Operation (Horn Strobe)

UL ULC CSFM Listed FM Notification Appliances Audible Visible Notification Appliances for 4 Wire Operation Horn mount audible visible notification appliances with efficient horn and high output xenon strobe for 4 wire applications strobe visible notification appliance 24 VDC operation with switch selection for free run or synchronized rate Models available with 15 75 or 110 candela UL listed to Standard 1971 Compatible with ADA requirements see Installation references Strobe candela rating is clearly indicated on reflector horn audible notification appliance Low current operation 25 mA 24 VDC Harmonically rich output sound suitable for either coded or steady UL listed to Standard 464 housing colors Red cover with white FIRE lettering White cover with red FIRE lettering easy and convenient semi flush or surface wall Easily mounts to single gang double gang or 4 inch square outlet box Optional mounting adapters are available to cover surface mounted boxes and to adapt to Autocall 2975 9145 boxes Diode polarized inputs for connection to reverse polarity supervised appliance circuit NAC In out wiring terminals for 18 AWG to 12 AWG accessible from front of providing easy access for installation inspection and testing Rear of housing assembly does not extend into box Rugged high impact flame retardant thermoplastic housing with covers available to convert housing color Optional UL listed red wire guard is available for semiflush or surface 1 Non Addressable A V Appliances are available in Red with Lettering and White with Red Lettering non addressable audible and visible notification For requiring audible visible A V notification with horn tones Autocall A4903 series appliances combine a high intensity strobe a low current electronic horn in a compact package that is easy and to install Each appliance can be controlled independently from other using conventional reverse polarity NACs models with flexible mounting choices These 4 wire A V appliances are available with three strobe intensity levels 75 or 110 cd and with red or off white housings Mounting can be or surface mount on a standard single or double gang or 4 102 mm electrical box Optional accessories are available to mounting and application flexibility selection selection of visible notification is dependent on occupancy local codes and proper applications of the National Fire Alarm NFPA 72 ANSI A117.1 the appropriate model building code ICBO or SBCCI and the application guidelines of the Americans Disabilities Act ADA This product has been approved by the California State Fire Marshal CSFM pursuant to Section 13144.1 of the California Health and Safety Code See CSFM Listings 7125 2269 0525 7300 2269 0553 7125 0026 0239 for allowable values and or conditions concerning material presented in this document Additional listings may be applicable contact your local product supplier for the latest Rev 7 1 2020 Audible Visible Notification Appliances for 4 Wire Operation Horn Strobe operation non addressable A V strobes can be set for free run operation or synchronized operation using an on board selection switch When for synchronized operation flash operation is controlled from Synchronized Flash Modules A4905 9914 Class B or A4905 9922 Class A 4006 4007ES Hybrid 4010ES and 4100ES Fire Alarm Control Panels refer to individual product data sheets for details 4009 IDNet NAC Extender models A009 9201 and A009 9301 refer to data sheet AC4009 0002 operation non addressable A V horns provide an audible notification output that is a loud and penetrating harmonically rich sound capable of a or coded output per the controlling NAC capabilities selection Notification Appliances Horn Strobe 1 Red housing with white FIRE lettering notification appliance output cd cd cd 2 White housing with red FIRE lettering notification appliance output cd cd cd 3 Adapters mount red adapter skirt mount white adapter skirt to cover 1 1 2 deep surface boxes adapter plate for mounting to 2975 9145 box typically for retrofit be mounted vertical or horizontal mounting box requires A4905 9931 adapter plate H x 5 1 4 W x 1 5 8 D mm x 133 mm x 41 mm Total with strobe 4 3 8 111 mm x 5 3 4 x 0.060 Thick mm x 146 mm x 1.5 mm x 5 1 8 x 2 3 4 Deep mm x 200 mm x 70 mm 4 Synchronized flash control modules Flash Module Class B Flash Module Class A encapsulated with in out 18 wire leads rated for 2 A NAC 10 mA for power W x 2 7 16 L x 13 16 H mm x 62 mm x 20 mm 5 Optional covers and guard cover with white lettering cover with red lettering guard with mounting plate red compatible surface or semi flush mounted boxes H x 5 W x 1 1 2 D mm x 127 mm x 38 mm H x 6 1 16 W x 3 1 8 D mm x 154 mm x 79 mm listed by Space Age Electronics Inc Dimensions including lens Range Range 6 General specifications in H x 5 in W x 2 3 4 in D 130 mm x 127 mm x 70 mm to 122 0 to 50 to 93 non condensing at 100 38 blocks for 18 AWG to 12 AWG 0.82 mm to 3.31 mm two wires terminal for in out wiring 2 Rev 7 1 2020 Audible Visible Notification Appliances for 4 Wire Operation Horn Strobe Listed Range Voltage Range Rate and Synchronized NAC Loading RMS Current Rating per Strobe Output see note Currents at other VDC VDC Voltage Range Output Characteristics Output and Current Ratings 10 ft 3 m 7 Strobe specifications 24 VDC see note 1 Hz with up to 35 synchronized strobes maximum per NAC cd mA mA mA 8 Horn specifications cd mA mA mA cd mA mA mA Listed Range VDC to 33 VDC see notes 3 and 4 to 3700 Hz sweep modulated at 120 Hz rate VDC Coded Type see note 5 mA mA Chamber UL 464 Test 85 dBA 82 dBA 88 dBA 84 dBA 91 dBA 87 dBA Chamber dBA 86 dBA 91 dBA 86 dBA 91 dBA 87 dBA Coded mA mA Coded mA mA VDC VDC 24 VDC refers to the voltage range of 16 to 33 VDC per UL Standard 1971 Signaling Devices for the Hearing Impaired This voltage is the absolute operating range Operation outside of this range may cause permanent damage to the appliance Please note that 16 is the lowest operating voltage that is allowed at the last appliance on the NAC under worst case conditions The strobe of this A V is field for free run or synchronized operation The maximum RMS current listed is the device nameplate rating Strobe designs are constant wattage and the maximum RMS current rating at the lowest allowable operating voltage RMS is root mean square and refers to the effective value of a varying current waveform Terminals are provided for wiring the horn and strobe of these A Vs to separate NACs Operation of the horn and strobe is not separately when they are both wired to the same NAC The rated voltage range listed is the absolute operating range Operation outside of this range may cause permanent damage to the appliance note that 16 VDC is the lowest operating voltage that is allowed at the last appliance on the notification appliance circuit under worst case Coded values are typical of the output measured with a Temporal coded or a March Time coded pulse and with a sound level meter reading on a setting Under the same test conditions coded horn output sound level readings are typically 4 dBA higher references 2 or semi
