Autocall TrueAlert ES Addressable Speakers USWeather Proof Wall Mount Notification Appliances Installation

TrueAlert ES Addressable US Weather Proof Wall Mount Speaker Notification Appliances Instructions warnings and regulatory information When the notification appliance emits light or sound it indicates the possibility of an emergency situation that requires immediate atten of all occupants Always install maintain and test notification appliances within their specifications Failure to follow all safety precautions instructions may result in loss of life and property due to non functioning notification appliances Some notification appliances high voltage To avoid electrical hazards and avoid damage to appliances make sure that the electrical power for the Notification Circuit is disconnected at the control unit before installing repairing or internally adjusting any notification appliances Even electrical power removed some notification appliances such as visible strobes store a high voltage charge The high voltage can injury resulting in death from electrical shock DO NOT TOUCH EXPOSED CIRCUITRY REFERENCE Location and quantity of appliances required must conform to the applicable local standards and guidelines National Fire Alarm and Signaling Code NFPA 72 ULC Standard CAN ULC S524 Installation of Fire Alarm Systems the appropriate building codes and specific requirements of the local Authority Having Jurisdiction AHJ These notification appliances are not for installation within hazardous locations as defined by the National Electrical Code NEC or NFPA appliances provide a speaker only SO or speaker visible S V warning of an alarm condition when activated from the control unit of a UL ULC Listed Autocall Fire Alarm System Consult Autocall Fire Alarm unit documentation for compatibility information The speakers can turned ON or OFF individually under compatible unit control Mount with cover colors Red White Mount Only with cover Red White 1 Products boxes boxes contents included x 1 one in thread forming screws x 4 a backplate separately for each appliance a back box listed above to mount the appliance assembly to the wall a cover listed above separately for each appliance For information about TrueAlert ES appliance testing see TrueAlert ES Addressable Appliances Testing and Application Guide 579 1049AC operation levels 49 S V appliances have multiple strobe intensity levels Levels W15 W75 W110 and W185 are rated for UL outdoor private mode applications 15 and 75 are rated for UL indoor and uncontrolled wet Public Mode applications box mounting instructions the mounting location and install the back box see the back box installation instructions or for more information the building wiring through the rectangular opening in the backplate the building wires to the backplate see Wiring instructions Rev B ES Addressable US Weather Proof Wall Mount Speaker Notification Appliances Installation the backplate to the electrical box using the provided hardware Install the backplate so that the contacts are above the opening for the the appliance settings See Setting the address DIP switch attach the cover to the appliance carefully move the cover over the housing Move the cover down over the housing and press it until it snaps the housing the assembled appliance to the backplate 1 box mounting instructions removal or disassembly Use a blade screwdriver to catch the latches on the left side of the cover angling the head out from the appliance and then lifting Repeat this on latch in turn until the cover rotates away a blade screwdriver into the gap between the housing and backplate at the bottom of the assembled appliance the head towards the appliance and lift When the housing moves toward you lift and pull the appliance away with your hand Ensure you do not compromise the gaskets when you disassemble the unit instructions Make sure that all power is disconnected before starting the installation Do not bring the conduit through the rear of the electrical box Strip the lead insulation to 7 16 in maximum the electrical box connect the building wiring to the CKT and CKT terminals on the backplate ensure proper continuity use a torque wrench to tighten the terminal block screws to 12 to 15 lb in that the correct polarity is maintained for each strobe unit wiring must be twisted pair TWP CKT Terminals accept 2 Wires 12 to 18 American wire gauge AWG TWP 2 Rev B ES Addressable US Weather Proof Wall Mount Speaker Notification Appliances Installation Wiring notes 2 instructions a maximum of 127 active appliances to a circuit Assign a maximum of 63 active strobe appliances to a powered circuit The wire resistance between appliances is 29 ohms Refer to the field wiring diagrams of the driving compatible fire alarm control for further instructions Notification appliances are rated using an individual module label Maintain the correct polarity on the terminal connections 1 through 6 each accommodate two wires one wire going in and one wire going out to the next appliance appliances are rated to the operating voltage limits of 23 VDC to 30 VDC The appliance can fail to operate as intended and can permanent damage to this equipment if it operates outside of these limits operate the TrueAlert IDNAC S V and SO using a compatible power supply and amplifier is not permitted for Class A wiring SLC wiring connections are supervised and power limited the address DIP switch addressable TrueAlert IDNAC notification appliance has a unique address that is set using an eight position DIP switch ADDR1 Assign up to 127 addresses an signaling line circuit SLC however the total appliance loading available may be less due to appliance current requirements set the address complete the following steps Use a non metallic stylus or the equivalent to set the switches DIP switch position 8 determines whether this appliance is viewed by the system as an ALARM OFF or ALERT ON type of appliance Confirm the steps to disassemble the unit see Unit removal or disassembly the set address setting for the appliance at this address with the FACU system configuration documentation DIP position 9 is not used set to OFF 3 Rev B ES Addressable US Weather Proof Wall Mount Speaker Notification Appliances Installation the strobe candela setting 3 the DIP switch address jumpers are factory set to FACU Use this setting when programming the candela level at the 4100ES FACU The candela setting is visible the slot on the side of the appliance manual selection remove the cover and slide the candela flag to the required setting The candela setting is visible through the slot on the of the appliance The settings are 15 W15,75 W75 W110 W185 candela or FACU To avoid a programming mismatch trouble an authorized service personnel must program one of the 6 candela outputs for each appliance To the candela through the Programmer set it to FACU For additional information refer to the ES unit Programmer Manual 574 849AC circuit configuration for S V and SO appliances the wire harness position to the correct terminal post for audio circuit voltage and power tap selection See Figure 4 and Table 4 4 the strobe and appliance configuration specifications DC Control Strobe Voltage Range temperature rating temperature rating humidity range 4 2 Environmental specifications APPLICATION 23 VDC to 30 VDC private 40 to 150.8 40 to 66 and uncontrolled wet Public Mode 32 to 122 0 to 50 to 120 40 to 49 non condensing at 140 60 Rev B ES Addressable US Weather Proof Wall Mount Speaker Notification Appliances Installation The appliance enclosures are available in red
