UNITY Commitment To Connectivity Continues I Net Subsystem DATA Information Johnson Contols CSI I Net sub is used in conjunction with the front end UNITY This allows the UNITY system to integrate the architecture of the CSI system into the UNITY front end used with other UNITY systems pulls together your entire facility fire life safety and security under one simple yet powerful environment UNITY improves efficiency by reducing operator requirements virtually eliminating on the original equipment for support Specific Information interface supports all I Net network with Revision 4.3 or higher All I Net Direct Connect and Auto Dial TAP configurations supported All I Net DCU and Unitary products are supported as well CSI I Net subsystem functions by full protocol level communica via the RS 232 port on the I Net Tap Model 78010 78012 78013 78016 7804 This provides the benefits Alarm Annunciation Status and Monitoring Control Capabilities Analog and Digital Commands Test Mode Commands Point Enable and Disable Setpoint Adjustments and Download of DCU Alarm Acknowledgment Limit Adjustments Listings Listed Integration of Access and Energy Manage Applications Listed under and 916s Synchronization of New York MEAs State Fire Marshal SPECIFICATIONS DCU DCU DLCU DPI MRI Unitary Controller Interface Industrial Communications Interface Building Manager Requirements Available RS 232 Port CSI Host TAP Model 7801 78012 78013 78016 7804 Requirements product requires a fully operational UNITY front manufactured by Johnson Controls OS 2 Revision 4.0 or Higher I Net Firmware Revision 4.3c or Higher Equipment Interface Hardware DCU DCU DCU DCU DCU DCU Controllers DPU DPU DIU DIO LAN Host Tap LAN Systems USA Inc HP 43 1024778 33K15 CONTACT 0 10 0 5 Card Reader Stripe Reader HP Processing Unit 43 1024778 33K15 CONTACT 0 10 0 5 Reader Reader HP HP HP HP more information on Johnson Controls products and services contact your local Johnson Controls office or call 800 765 7773 Johnson Controls Inc Controls reserves the right to update specifications when appropriate in U S A Information contained in this document is based on specifications believed to be correct at the time of publication I Net Micro Regulator IBM and OS 2 are registered trade marks and service marks of companies other than Johnson Controls Johnson Controls products and services are not or approved by those companies and Johnson Controls has used those marks without the authorization of those companies
