Ditek 1F31X & AC31X Datasheet

DTK 1F31X DTK AC31X Dialer Surge Protection Product Specifications 1F31X and AC31X surge protectors were designed with input from professional alarm installers Both the 1F31X and AC31X protect AC power to alarm control panels and RJ31X circuits The 1F31X is designed for use with alarm panels that connect directly to 120V AC its extra length retention screw secures the alarm panel transformer The AC31X is designed use with hard wired alarm systems where the transformer is separate from the alarm panel Application Features Protects dialer circuit terminal strip connection Protects 120V power 1F31X or 24V power AC31X Automatic reset to protect against repeated surges Specifications Specifications Approvals UL 1449 2nd Edition 2007 UL497A Voltage 120VAC Power 105VAC Telco 130VAC Power and Telco Method NEMA 5 15 Power Approvals FCC Part 68 Compliant Voltage 24VAC Power 105VAC Telco 30VAC Power 130VAC Telco Method Screw Terminal Power Terminal Telco Continuous Current Power 15 Amps 150 milliamps Surge Current 13,500 A Power 240 A Telco Modes Power L N L G N G Line Ground All Temperature 40 158 40 70 Humidity 95 non condensing 2.7 x 1.85 x 1.25 x 47mm x 32mm 4oz 113g ABS Ten Year Limited Warranty Terminal RJ31X Telco Continuous Current Power 5 Amps 150 milliamps Surge Current 200 A Power 300 A Telco Modes Power Telco Line Ground All Temperature 40 158 40 70 Humidity 95 non condensing 4 x 1.75 x 1.25 x 44mm x 32mm 4oz 113g ABS Ten Year Limited Warranty DITEK Center Starkey Road FL 33771 Direct 727 812 5000 Support 1 888 472 6100 Number SPS 100065 002 Rev 1 9 07 DITEK Corp Subject to Change
