Edwards 111 Series Installation Instructions

WIRING DIAGRAM OFF ELECTRICITY remove fuse or switch off circuit IS A RISK OF FIRE AND ELECTRICAL SHOCK SHOULD BE INSTALLED BY A QUALIFIED IN ACCORDANCE WITH NATIONAL LOCAL CODES INSTALLATION Make sure electricity is turned OFF Put weatherproof gasket in position under cover Connect wires as shown in diagram Attach fixture to junction box with 4 screws supplied lamp glass globe and aluminum guard Tighten set Turn on power INSTALLATION RELAMPING Use 150 watt incandescent lamp Maximum See socket for selection Disconnect power and let lamp cool if it was in operation Loosen set screw and unscrew aluminum guard and glass Replace lamp Replace glass globe and aluminum guard reconnect power CT 203 699 3300 203 699 3365 CUST SERV TECH SERV 3100464 ISSUE 1 2002 EDWARDS
