Edwards 200 Class 36 mm Stacklight Data Sheet

200 Class 36mm 200 Class 36mm Stacklight is a versatile signaling device that may contain up to six light modules or five modules and one sounder module in a single integrated stack The lens modules are available with LED light and in red amber green blue yellow and white The 36mm is available as a Steady Burn LED device The are made from a self extinguishing polycarbonate material and are scratch and impact resistant optional piezoelectric sounder module complements the 36mm visual signals of the Stacklight The sound has been designed so that it always sits in the top position of the Stacklight 200 Class 36mm Stacklight features an interlocking system for quick assembly without any tools It is available industrial gray or basic black and offers multiple voltage ranges to provide solutions for most industrial applications also meeting machine builder and OEM requirements Available in Industrial Gray or Basic Black Stackable up to six total modules including sounder Quick and simple assembly with NO tools required Optional Piezoelectric Sounder one single tone 72dB Available in 24VAC DC Operating Temperature 22 to 122 30 to 50 Class 36mm Features cULus Listed IP65 without Sounder CE approved Six lens colors LED light source Steady Burn Class 36mm Base and Cover Gray Class 36mm Modules Gray Type Color Voltage A 1m No No AC DC AC DC AC DC AC DC AC DC AC DC AC DC Acoustic Gray Add to end of the catalog number for Basic Black unit voltage frequency is 50 60 Hz Sheet ES001 0121 Issue 1 to be used for installation purposes 1 of 2 Box Footing with Extension Extension Pole NPT Wall Mount Threaded Wall Mount Box Gray with Extension Gray Extension Pole 100mm Gray Footing Gray Wall Mount Gray Threaded Wall Mount Gray Flexible Steel Extension Stem 370mm Stainless Steel Extension Stem 100mm 270SSXT100 Stainless Steel Extension Stem 200mm 270SSXT200 Stainless Steel Extension Stem 400mm 270SSXT400 Female Adapter Base Gray No Add to end of the catalog number for Basic Black unit Drawings Module and Cover Module Approvals Steel Stem Steel Stem Farm Springs Road CT 06032 Copyright 2011 Edwards Signaling Sheet ES001 0121 Issue 1 to be used for installation purposes 2 of 2
