Edwards 200 Class 48 mm Stacklight Data Sheet

200 Class 48mm 200 Class 48mm Stacklight is a versatile signaling device that may contain up to light modules or 4 light modules and 1 sounder module in a single integrated stack lens modules are available with LED light sources and in red amber green blue yellow and white 48mm Stacklight comes as a Multi Mode device so the user may choose either the steady burn or flashing mode lenses are made from a self extinguishing polycarbonate material and are scratch and impact resistant optional magnetodynamic sounder module complements the 48mm visual signals of the Stacklight The sound has been designed so that it is always in the top position of the Stacklight 200 Class 48mm Stacklight features an interlocking system for quick assembly without any tools It is available in gray or basic black and offers multiple voltage ranges to provide solutions for most industrial applications while meeting machine builder and OEM requirements Class 48mm Stacklight Features cULus listed CE approved IP65 without Sounder Six lens colors Three different light sources Multi Mode Steady or Flash user selectable Available in Industrial Gray or Basic Black Stackable up to 5 total modules including sounder Quick and simple assembly with NO tools required Optional Magnetodynamic Sounder one single tone 77dB Multiple voltage options Operating temperature 22 to 122 30 to 50 Class 48mm Stacklight Base Cover and Foot Gray Class 48mm LED Lens Modules Gray Acoustic Gray No Color Voltage A 1m Amber Red Green Yellow White Amber Red Green Yellow White Amber Red Green Yellow White AC DC AC AC AC DC AC AC in this position designates lens LED color A amber B blue G green R red W white or Y yellow Add to end of the catalog number for Basic Black unit voltage frequency is 50 60 Hz Sheet ES001 0122 Issue 1 to be used for installation purposes 1 of 2 Drawings with Extension Extension Pole Module Cover and Foot Box Footing Wall Mount Threaded Wall Mount Box Gray with Extension Gray Extension Pole 100mm Gray Footing Gray Wall Mount Gray Threaded Wall Mount Gray Flexible Steel Extension Stem 370mm Stainless Steel Extension Stem 100mm 270SSXT100 Stainless Steel Extension Stem 200mm 270SSXT200 Stainless Steel Extension Stem 400mm 270SSXT400 Female Adapter Base Gray No Add to end of the catalog number for Basic Black unit NPT Module Approvals Steel Stem Steel Stem Farm Springs Road CT 06032 Copyright 2012 Edwards Signaling Sheet ES001 0122 Issue 1 to be used for installation purposes 2 of 2
