SYNCHRONIZED TIME SYSTEMS Digital Clock Scoreboard Edwards Catalog 2000 DCT Clock Timer Controller is a com microprocessor controlled unit that enables an Edwards two or Digital Secondary Clock to be used for timing count down score keeping and code blue timing unit is designed for ease of use with logical button groupings labeling and LED function guidance When a particular op mode is selected related LEDs illuminate to indicate the available in that mode A lock out feature allows the panel controls to be disabled preventing unauthorized use 2000 DCT and its associated clock can operate as a stand clock timer or as a secondary clock under the corrective con of an Edwards 2000 MTC Master Time Program Clock The unit powered by separate 24VAC or 15 VDC power use the Edwards power supply unit has five operating modes In the first clock mode the operates under the control of a master clock In the ab of a master clock the timer controller can operate in stand mode governing the time for its associated digital clock mode does not provide battery backup second and third modes Count Up Timer Mode and Count Timer Mode count up from zero or down to zero from a user start time The timer can count by minutes and hours or seconds and minutes The unit can be set to run silent or to at determined increments The fourth mode Score Board uses the digital clock as a simple score board The two left of the clock display the score of team 1 and the two right dig display the score of team 2 The last mode Code Blue Timer shows the elapsed time from when a code blue call is placed when the STOP button is pressed on the controller Copyright 2004 Edwards User friendly front panel controls Controls Edwards two inch digital clocks Operating modes 12 or 24 hour clock Count down timer Elapsed timer Score board Code blue elapsed timer Operates independently or as a to a master clock Timer display settings Hours minutes Minutes seconds Textured gray ABS bezel Textured gray polycarbonate 10V DC 110mA to 15V DC or 10V AC 91mA to 24V 50mA use 2000 DCT PS supply Mounts in standard three or four electrical backbox 32 to 90F 0 to 32C Fieldstone Court Cheshire CT 06410 h 2 0 3 6 9 9 3 3 0 0 F x 2 0 3 6 9 9 3 1 0 8 TIME SYSTEMS INFORMATION 1 2 1 8 Copyright 2004 Edwards Fieldstone Court Cheshire CT 06410 h 2 0 3 6 9 9 3 3 0 0 F x 2 0 3 6 9 9 3 1 0 8
