Edwards 2000-SC Series Catalog Page

SYNCHRONIZED TIME SYSTEMS Clocks Series Edwards 2000 SC System Clocks are two and four inch Digital that provide a highly visible time display The 2000 SC4 clock is visible for 160 feet 48.8m in the bright intensity and 150 feet 45.7 feet in the normal intensity mode The two inch clock is visible for 110 feet 33.5m in the intensity mode and 100 feet 30.5 feet in the normal intensity Either unit can be operated in either 12 or 24 hour format minute the time display on the clock updates to the master time This ensures that all clocks in the system are in exact and that every clock in the system is as accurate the master clock with FCC Part 15 Class A emissions has been verified as a result the 2000 SC System Clocks meet the require for installation in educational institutional and commercial The installed clock is ESD hardened to IEC 801 2 Standards new installations the clocks flush mount into RACO 693 4 masonry backbox 2 1 2 6.4cm deep or RACO 698 3 1 2 deep or approved For surface mount installations use the No 2000 SC4 SMB surface mount box for four inch clocks and Cat No 2000 SC2 SMB for two inch clocks Highly visible two four inch displays 24VAC operation Selectable LED display intensity 12 or 24 hour display High efficiency APPROVALS FCC Part 15 Class A ESD hardened to IEC 801 2 350mA 4 inch bright mode 4 inch normal mode 2 inch bright mode 2 inch normal mode Pigtail Terminations Antiglare acrylic lens Charcoal gray ABS Plastic Bezel Fieldstone Court Cheshire CT 06410 h 2 0 3 6 9 9 3 3 0 0 F x 2 0 3 6 9 9 3 1 0 8 Copyright 2004 Edwards TIME SYSTEMS INFORMATION 1 2 3 4 No 15 16 EQUIPMENT 2000 SC PS AC Clock Power Supply a convenient source of 24VAC power for the 2000 Series system clocks The low and current output of this supply allows 2 wiring to be used An onboard relay allows correction to be easily interfaced with the master clocks The supply mounts in the 2000 SC PS BB power supply backbox the 2000 SC PS BBSD surface door power supply measures 4 1 2 11.4cm high 14 1 4 36.2cm wide by 3 5 8 9.2cm deep surface door measures 14 11 16 37.3cm by 15 38.1cm wide by 1 2 1.2cm deep backbox measures 14 1 2 36.8CM high by 38.1CM wide by 4 10.2CM deep Copyright 2004 Edwards 2000 SC4 DMB Dual Four Inch Digital Housing for corridors or large rooms requiring a and rear digital clock display The enclosure two Edwards four inch 2000 SC4 clocks separately The 2000 SC4 DMB may wall or ceiling mounted For mounting to a ce or cinder block wall the housing mounts to a RACO two gang masonry box Optionally housing can be flush mounted to the ceiling or below the ceiling using conduit exten The unit measures 7 17.8cm high by 19 wide by 4 1 2 11.4cm deep and is fin in charcoal gray Fieldstone Court Cheshire CT 06410 h 2 0 3 6 9 9 3 3 0 0 F x 2 0 3 6 9 9 3 1 0 8
