Edwards 2455C Series Catalog Page

FIRE ALARM EQUIPMENT Chime Low current draw Supervised wiring Terminals for easy wiring Red or white flame resistant Adjustable volume control APPROVALS UL 464 Listed Indoor Fire Alarm Mode CSFM Listed Series Edwards 2455C series electronic chimes are audible signals for use with life safety control equipment The 2455C is for indoor mounting on a Catalog No 2459 SMB surface back box or flush mounting to a standard 4 102mm square 2 1 8 54mm deep electrical box 2455C chimes are audible signaling appliances for installations operate in conjunction with an installed fire alarm panel and de devices No mount box red mount box white 1 2 1 2 Number Voltage Current Output Red White 24V DC 20 to 24V DC Continuous Non pulsed mA 24V DC 12 mA 24V DC FWR Maximum volume setting 24V DC 64dBA Minimum volume setting 20 24V DC Fieldstone Court Cheshire CT 06410 h 2 0 3 6 9 9 3 3 0 0 F x 2 0 3 6 9 9 3 1 0 8 Copyright 2004 Edwards
