Edwards 5531M and 5531MV Installation Sheet

and 5531MV Series Installation Sheet 5531M and 5531MV Series Adaptatone signals are intended for applications where high audible output and microcomputer are required The 5531M and 5531MV Series Adaptatone are for indoor outdoor use and are UL and cUL Listed as Signal Appliances for use in the hazardous locations listed in 1 device operates from local power It accommodates up to four contacts on its inputs The tone that sounds in response an active input is determined by setting miniature programming inside the unit Table 6 shows the switch settings for the tones tones may be programmed into the unit at any time These tones on a pyramid type priority system The tone programmed on overrides the tones programmed on SW2 SW3 and SW4 The on SW2 overrides the tones programmed on SW3 and SW4 the tone on SW3 overrides the tone programmed on SW4 tone programmed on SW4 has the lowest priority and cannot any other programmed tone speaker direction and the output level are easily adjustable equipment is suitable for use in Class I Division 2 Groups A B and D Class II Division 2 Groups F and G Class III hazardous or nonhazardous locations device may be mounted on any flat surface or may be used as a unit mounted on a rigid pipe The Adaptatone must be in accordance with the latest edition of the National Electrical or other regulations applicable to the country and locality of and by a trained and qualified electrician model numbers ending in AQ 24 VAC power must be transformer from mains or line power Explosion hazard Do not disconnect equipment unless power has removed or the area is known to be nonhazardous Explosion hazard Substitution of any components may impair for Class I Division 2 To ensure integrity of the Adaptatone assembly when adjusting the direction make sure threads in the enclosure remain fully and do not turn speaker more than 360 degrees from the factory installed position To prevent fire shock and component damage no work including board removal should be performed while the circuit is High voltage is present when the product is energized High volume may cause harm to personnel in close proximity ensure integrity of the enclosure Be sure that the cover gasket P N P 007549 0069 is adhered into groove at the cover perimeter before replacing the signal box Be sure that the four collar gaskets P N P 041930 0362 are in on each cover screw before securing the signal box cover When securing the cover start the screws by hand making sure they are threaded into the tapped holes in the housing bosses securing them with a screwdriver Torque the signal box screws to a minimum of 20 in lbs This ensures the required fit Any kind of service or maintenance performed while the unit is will void the warranty install the Adaptatone Mount the Adaptatone as shown in Figure 1 Surface mounting Secure the unit to the mounting surface the four mounting holes in the mounting plate on the rear of box Use the 10 3 wood screws furnished loose or other not supplied suitable for the mounting surface Pipe mounting Loosen the four cover screws from the box and lift off the signal box cover The cover screws are captive Do not remove them from the the center knockout in the lower wall of the box and the box on a 1 2 in conduit pipe using a suitable connector Wire in accordance with the instructions in on page 2 Refer to Figure 5 and Table 6 and select the desired tones Set the programming switches on the input board input connected to IN1 set on SW1 IN2 set on SW2 IN3 set SW3 and IN4 set on SW4 in order of priority desired Adjust volume level if desired by turning the potentiometer on the main board Figure 5 and Figure 6 Tightly secure the signal box cover using four retained cover Torque signal box cover screws to a minimum of 20 in lbs To adjust speaker direction loosen the large star nut Figure 1 turn the speaker to the approximate desired position the nut and turn the speaker slightly clockwise until it is into place of speaker direction adjustment it is important that the nut be tightened wrench tight to ensure that the speaker is maintained securely Verify operability 3100008 EN REV 06 ISS 14JAN15 8 1 Adaptatone mounting Speaker Large star nut to adjust speaker direction Signal box Cover screws 4X Collar gaskets 4X Raceway and connections not supplied to 1 2 in knockout hole 10 3 screws or hardware suitable for the mounting surface To prevent fire and shock wire the Adaptatone only as described this installation sheet When wiring units with replaceable fuses ensure that an adequate suitable for the location is provided to remove power from fuse Remove power before servicing the fuse Terminal Block TB1 can be unplugged from the main board to wiring as shown in Figure 2 and Figure 3 wire the Adaptatone wires through a knockout hole in the bottom of the box from raceway that is with its connections to the 1 2 in conduit hole approved for the same degree of protection and type needed by the application Use the provided plastic wrap on the barrier to the electronics to separate incoming leads from signal and tone initiating leads per NEC 4 Wire as follows referring to Figure 4 Edwards Signal Actuator model number 5538 4 is used to initiate tones connect its four normally open switches to tone generator as shown on the instructions provided with the Actuator unit Connect the green and yellow striped earth ground wires to ground Select the appropriate method for wiring to the input board Figure 7 through Figure 11 for models with 24 V input and Figure 12 and Figure 13 for models with 120 V boards Connect incoming power to wire leads using a butt splice or method listed certified or otherwise approved by local Leads are both black for AQ and N5 models and black and white for Y6 models Optional Connect an external 24 VDC battery not supplied in with the separate diode assembly P N 2600010 to TB1 terminals 3 and 4 on the main board as in Figure 3 and marked on the diode assembly a voice message 5531MV series High voltage is present when product is energized High volume may cause harm to personnel in close proximity record a message Put switches A and B on the programming DIP switch in the proper for the message to be recorded Figure 6 For a message longer than five seconds use message 1 Sec Sec Sec Sec A B Put switch PGM on the programming DIP switch in the CLOSED for programming mode Figure 6 Press and hold the record button while speaking clearly into the to record your message Release the button when is complete To test the message press and hold PLAY while in programming This will play only the current location Adjust the volume as necessary Set the main volume using the on the main board Figure 5 and Figure 6 and then the voice volume using the potentiometer on the voice module Figure 6 2 Terminal block TB1 Terminal block TB1 Main board 3 Wiring to terminal block TB1 input circuit To internal power supply factory installed Diode assembly P N 2600010 To optional 24 VDC battery backup 8 3100008 EN REV 06 ISS 14JAN15 4 Wiring the Adaptatone 5 PC board locations board Direction of increasing volume Processor board Voice module board Voice module potentiometer for adjustment Microphone Record LED Play Record Terminal block TB1 Programming DIP switch Switches shown in OFF down position Programming DIP switch Power and earth ground leads Plastic cable wrap pr
