Edwards 5535 Installation Instructions

EDWARDS Instructions for Remote Amplifiers Series 5535 and Operation remote amplifiers are designed to accept tones voice music inputs from 5541 System control units or tones from Series Tone Generators The amplifiers convert the input to 70V line output up to 15 watts to sound on speakers remote locations The remote amplifiers are UL listed and certified as audible signal appliances for general signaling alarm use Specifications 7 Pounds 3.2 kg Ambient Temp 31F to 151F 35C to 66C Specifications POWER 60 Hz 50 Hz DC 60 Hz 50 Hz DC Current A On A should be completed in accordance with applicable codes and the latest edition of either NFPA 70 National Code or CSA C22.1 Canadian Electrical Code 5535 Series Remote Amplifier may be mounted to any flat or may be used as a freestanding unit mounted to a rigid During installation take care not to damage the on the printed circuit board Mount Adaptatone Figure 2 Remove 4 cover screws from the signal box and lift off Flat Surface Mounting Secure unit to mounting surface the 2 mounting holes in rear of box with furnished and 10 X 1 1 2 38 mm screws supplied mounting to dry wall or concrete surfaces use O rings and suitable hardware not supplied Rigid Pipe Mounting Seal the 2 mounting holes in of box with 2 furnished O rings and 12 X 3 8 mm long screws the center knockout in lower wall of box and box to a 1 2 12.7 mm conduit pipe using connector not supplied wires through a knockout hole in the bottom of the when the signal is mounted to a flat surface or through pipe when the signal is freestanding In areas of high noise use shielded audio cable 1 Dimensions CT 203 699 3000 FAX 860 677 7746 ISSUE 3 1998 Wire Adaptatone as follows Standby Power Optional Figure 3 2.5 to 3 ampere hour 24V DC battery is recommended standby power This type of battery provides 24 hours standby service standby power to 5535 TB1 B and terminals Observe polarity Adjust volume level if desired by turning potentiometer 3 or 4 Replace the signal box cover Verify operability as follows a signal and verify that is sounds on all the connected to the Remote Amplifier Reset device standby power is used verify that it will function Remove the 120V AC or 240V AC power a signal and verify that is sounds on all speakers are connected to a Remote Amplifier Reset the device and restore 120V AC or 240V AC power and Test prevent electrical shock ensure that power is before cleaning inside of unit the unit semi annually for accumulation of dirt Clean necessary Remote Amplifier should be tested annually or as required the authority having jurisdiction to ensure continuous service 2 Remote Amplifier Mounting Connecting 5535 Amplifier s to 5541 System Control Figure 3 the wires from the 5541 System Control unit Out L and H terminals to the 5535 Remote TB2 L and H terminals Observe polarity For system connections see instructions P 047550 shipped with the 5541 System Control Units Connecting 5535 Amplifier s to 5541B System Units Figure 3 the wires from the 5541B System Control unit Area 1 Audio Out terminals to the 5535 Remote TB2 L and H terminals Observe polarity For system connections see instructions P 047550 shipped with the 5541B System Control Units Connecting 5535 Remote Amplifier s to a Series 5540 5540A Central Tone Generator Figure 4 the wires from the Central Tone Generator TB2 and LO terminals to the 5535 Remote Amplifier TB2 and L terminals Observe polarity For other system see instructions P 047550 0179 shipped 5540 Series Central Tone Generators or P 047550 shipped with 5540A Series Central Tone Connecting 5535 Remote Amplifier s to a Series Central Tone Generator Figure 4 the wires from the Central Tone Generator TS1 and 10 Tone Out terminals to the 5535 Remote TB2 H and L terminals Observe polarity For system connections see instructions P 047550 shipped with 5540B Series Central Tone Generators Speaker Connections Figure 3 or 4 The Remote provides up to 15 watts audio power to 70V speakers For best service use the Edwards 5547 5551B Series Speakers the speakers to the two yellow wires coming the transformer that is mounted on the Remote printed circuit board Power Supply Connections Figure 3 or 4 prevent electrical shock do not apply power all system wiring is completed and all covers secured the AC power source wires to the two black wires coming from the transformer on the inside of the remote amplifier ISSUE 3 3 Remote Amplifier Wiring to System Control 5541B Series Shown 4 Remote Amplifier Wiring to Central Tone 5540B Series Shown ISSUE 3
