Edwards 5551B-2W Installation Instructions

Installation Instructions for Catalog Number Ceiling or Wall Mounted Cone Speaker Catalog Number 5551B 2W speakers are voice tone no appliances designed for indoor ceiling or wall mount and offer low power consumption multi watt power se and high sound level output They are primarily in for use with the 5535B Remote Amplifier product is UL listed in accordance with the latest edition NFPA 72 National Fire Alarm Code to Table 1 and Figure 1 for speaker specifications reduce the risk of shock always disconnect all before handling the unit device will not operate without electrical power fires frequently cause power interruptions discuss safeguards with your local fire protection supervision requires wire run to be broken each device reduce the risk of shock do not attempt to repair unit Contact supplier for replacement Select a mounting method as detailed in Figure 1 electrical box using suitable hardware Bring installation wiring into electrical box from a control panel that provides 70V RMS Ground accordance with local codes and regulations Obtain desired sound level power tap information from 1 Connect positive audio wire for the intended output to the appropriate terminal located on the of the speaker unit Figures 2 and 3 Connect audio output wire to terminal marked C Do loop signal circuit field wires around terminals When connections are complete position the speaker onto the electrical box and align the holes on electrical box with the speaker mounting holes Figure Secure the unit onto the electrical box using the 8 X 1 1 2 38 mm truss head screws provided the two cap plugs into the unused mounting holes Apply power and activate the speaker unit to verify that is operating properly regularly scheduled testing at least twice a year or often as dictated by the local authority having jurisdic 1 Mounting the 5551B 2W Cone Speaker CT 203 699 3000 FAX 203 699 3075 ISSUE 1 1997 1 Sound Output Specifications Number Voltage RMS Pressure Level at 10 feet 3.05 m in a reverberant room 400 4,000 Hz band limited pink noise per UL 1480 dBA dBA dBA dBA 5551B 2W cone speaker is supplied with a white baffle 2 Terminal Block 3 Wiring Diagram for Speaker Unit ISSUE 1
