Edwards 7005-G5 Installation Instructions

Installation Instructions for the Hotel Room Annunciator 7005 G5 Hotel Room Annunciator Kit alerts hearing impaired inside a room that someone is present outside the The horn strobe is mounted inside the room When the outside of the room is pressed for 5 seconds the signal activated The 7005 G5 Hotel Room Annunciator Kit contains Cat No 620 Pushbutton Mounting Plate Cat No Horn Strobe Cat No 6536 G5 and Transformer Cat 592 You can purchase each item separately from your local distributor qualified electrician familiar with National Electrical Code local code requirements must install this product Failure to the safety precautions in this instruction sheet could result product or property damage severe personal injury or death reduce the risk of shock do not connect AC power installation is complete Cat No 620 Pushbutton and Cat No 147 10 mounting Figures 1 and 2 the back of the pushbutton through the hole in the plate Press on the button until it is properly within the hole a single gang 2 x 4 51 mm x 102 mm electrical using suitable hardware Extend black and white wires using 18 AWG wire and not supplied Route extended wires to the and transformer polarity is not important in accordance with local codes and regulations Mount the pushbutton switch onto the electrical box 2 screws supplied with the Cat No 147 10 plate additional pushbuttons are required follow steps a and above Then extend black and white wires using 18 wire and connectors not supplied Route extended to the previously installed pushbutton switch and wire leads Figure 1 Catalog No 6536 G5 horn strobe Figures 1 and 4 reduce the risk of shock do not remove lens or with unit when the circuit is energized power and allow five 5 minutes for energy to dissipate before starting work or High energy could be stored in the circuit once it is energized 6536 G5 horn strobe can be mounted on any single gang x 4 51 mm x 102 mm electrical box double gang 4 x 4 mm x 102 mm electrical box or standard 4 x 4 102 x 102 mm junction box with a plaster ring an appropriate electrical box using suitable Connect one wire from the 620 pushbutton to one of the wires polarity is not important Extend the remaining horn strobe wire to the transformer Mount the horn strobe onto the electrical box using two supplied Catalog No 592 Transformer Figures 1 and 3 a metal electrical box that can be grounded Mount transformer onto the electrical box Figure 3 so that has ground continuity to the box and conduit system the box using suitable hardware Ground the box in accordance with local codes and Connect the remaining pushbutton wire to one of the marked 24V 20VA Connect the horn strobe wire to the second terminal 24V 20VA Connect the transformer primary wire leads to an 120V AC power source When all connections are completed press the pushbutton verify operability of the horn strobe regularly scheduled testing at least twice a year or more as dictated by local authorities having jurisdiction 7005 G5 Hotel Room Annunciator is not serviceable or re Should it fail to operate properly contact the supplier replacement Voltage Current Primary Secondary 1 Specifications 50 60 Hz mA DC mA 20VA CT 203 699 3300 FAX 860 677 7746 ISSUE 1 1999 No 620 No 147 10 box for No 620 and No 147 10 box for No 620 and No 147 10 electrical for 592 Transformer 120V AC source for 1 Connecing Catalog No 7005 G5 Hotel Room Annunciator 3 4 mm Mounting foot mounts Mounting Mount inside a standard gang electrical box using a Catalog 593 5 16 mm 1 4 mm FOR 1 2 mm DEPRESS SECONDS 591 6536 G5 1 10VA 1 8 mm 20VA mm on Box Remove 1 2 13 mm knockout electrical box Loosen the from transformer bracket position the transformer on the box so that the bracket into the box Tighten the 2 Catalog No 620 and Catalog No 147 10 3 Catalog No 592 Transformer mm 9 16 mm 1 2 mm 591 620 installed ISSUE 1 4 Catalog No 6536 G5 Horn Strobe
