Edwards 96 Series Div 2 Flashing Xenon Catalog Page

Edwards 96DV2 Series Xenon strobe beacons light duty visual signals suitable for use in commercial and institutional where short term intermittent visual is required Optically designed fresnel improve viewer perception for indoor and wet locations requiring Division 2 NEMA Type 4X specifications 96DV2 Series can be panel or conduit Trigger and timing circuits are included integral parts of the power supply Replace costs are reduced as it is necessary to only the strobe tube and Specifications Xenon strobe light source Flash rate 65 fpm Optically designed fresnel lenses Resistant to shock and vibration Suitable for indoor and outdoor applications For outdoor use lens should face up NEMA Type 4X enclosure Class I Div 2 Groups A B C and D Class II Div 2 Groups F and G Class III Option for panel or conduit mounting Operating temperature range 31 to 150 to 66 A B C No AC AC AC AC AC AC A A A A A A Tube hour2 Temperature Code 160 320 85 185 85 185 in this position designates lens color A amber B blue C clear G green M magenta or R red Xenon Series Information Strobe voltage frequency is 50 60 Hz at operating power to 75 efficiency Listings No TEMP Xenon Series and Dimensions No in this position designates lens color A amber B blue C clear G green M magenta or R red lb Net lb Shipping 1 8 series 01 eps
