Edwards AE Bulletin, fire with multi zone voice evac

120210 2 December 2 2010 E FS Series Fire Alarm Panels With Multi Zone Audio Diagram FS Panel With Multi Zone General Alarm Audio 1 Input Visual note 1 Audible note 2 In Booster Supply note 3 Series Alarm Panel 50 100 Notification Panel note 3 note 4 ANSZS4B Zone Splitter 1 2 3 4 1 2 3 4 Genesis Strobe Genesis Strobe Genesis Strobe Genesis Strobe NAC1 on fire alarm panel should be configured as Genesis NAC2 on fire alarm panel should be configured as Continuous End of line resistor value on TB3 5 and TB3 6 of audio panel must match the resistor used on TB2 1 and of zone splitter module Value can be between 2.2K and 100K ohms End of line resistor value on TB3 1 and TB3 2 equals the value used by the fire alarm panel s NAC signal Speaker circuit wiring should be 18 gauge minimum twisted pair shielded if necessary if run in noisy areas Be sure to observe polarity Strobe circuit wiring should be 18 gauge pair minimum twisted shielded not required 4 zone splitter module mounts in same cabinet as Audio Notification Panel Refer to splitter module s instructions for detailed interconnect drawings Refer to installation manuals for fire alarm booster power supply and ANS audio notification panel for wiring instructions Signaling Part of UTC Fire Security 41 Woodford Ave Plainville CT 06062 800 336 4206 Web edwardssignaling com E mail signaling techsupport fs utc com 1 of 1
