Edwards AE Bulletin, fire with voice evacuation

120210 3 December 2 2010 E FS Series Fire Alarm Panels With Single Zone Voice Evacuation Edwards E FS series fire alarm panels can be used in conjunction with the Edwards series audio notification panels when voice evacuation and paging are required is a diagram showing a system with a single speaker circuit and strobe circuit Visual note 1 Audible note 2 or 70Vrms Audio Series Alarm Panel note 4 note 5 4 5 6 note 3 50 100 Notification Panel note 6 Genesis Strobe Genesis Strobe NAC1 on fire alarm panel should be configured as Genesis NAC2 on fire alarm panel should be configured as Continuous J1 jumpers should be installed End of line resistor value equals the value used by the fire alarm panel NAC signal circuit End of line resistor value must match the resistor used for the speaker circuit end of line For if the speaker circuit is using a 10K ohm eol resistor the resistor connected here must be 10K Resistor value can be between 2.2K and 100K ohms The evacuation message is activated by the NAC input from the fire alarm panel Closing a dry across terminals Tb2 7 2 9 will activate an auxiliary all clear message This input is during an alarm the system must be restored to normal before using Speaker circuit and strobe circuit wiring should be 1 pair each of 18 gauge minimum Speaker wiring be at least twisted pair shielded if necessary if run in electrically noisy areas Be sure to polarity Refer to installation manuals for fire alarm and ANS audio notification panel for detailed wiring Signaling Part of UTC Fire Security 41 Woodford Ave Plainville CT 06062 80 336 4206 Web www edwardssignaling com E mail signaling techsupport fs utc com 1 of 1
