Edwards B-KBP-5060-N5

Installation Instructions for Catalog Number Remote Call Bell 1 Dimensions Edwards Catalog Number B KBP 5060 N5 Remote Call is a completely self contained 120V 60 Hz remote tele ringing unit that operates on ringing or key voltages The Call Bell can be activated by either AC or DC voltage provides 100 dB at 10 feet Remote Call Bell is weather and dust resistant and can be either indoors or outdoors devices are intended for connection to single line or key systems only They are not intended for on party line or on coin telephone lines When installed in accordance with these instructions the can be readily disconnected without affecting remaining on the telephone network with the Federal Communications Commission compliance with Part 68 of FCC Rules and Regulations TELEPHONE INFORMATION following information may be required by the telephone Telephone Number FCC Registration Number Ringer Equivalence Number REN at greater than 50 Volts and 3.4B at less than 50 Volts REN allows the installer to determine the number of de that can be added to the telephone line and still have all devices ring when the number is called In most but not all the sum of all RENs for all devices connected to your line not exceed five To be sure of the number of devices you connect to your telephone line contact your local telephone these devices damage the telephone network the telephone will notify the owner that it may temporarily discon service if they consider such action necessary If the owner the disconnection unwarranted they have the right to a complaint to the FCC 2 Wiring Diagram telephone company may make changes in its communica facilities equipment operations or procedures when such is required If these changes render the devices incom with the telephone company facilities the telephone com will provide enough written notice so that necessary changes be made in order to maintain uninterrupted service SPECIFICATIONS No Complete Desc Phone Bell AC Hz DC Switching Amps AC DC CT 203 699 3000 FAX 203 699 3075 ISSUE 1 1996 Mount backbox to wall or other surface with screws and fiber provided Fiber washers must be located between head and backbox to ensure weather tight seal Attach conduit and feed telephone cable through conduit or cord grip in the 3 4 19.05 mm tapped hole at of box Connect telephone leads to terminal screws on PC board 2 Attach conduit and feed AC cord through conduit or cord grip in the 3 4 19.05 mm tapped hole at of box Connect AC supply to Input terminal screws the PC board Figure 2 If bell rings continuously reverse the telephone leads at board Match tongue on top of weatherproof backbox to slot on top bell housing to attach bell Ensure rubber gasket is seated on back of bell housing and tighten bottom screw on housing ISSUE 1
