Edwards Data Sheets Genesis Ceiling Speaker-Strobes

Edwards Signaling Catalog u Speakers Telephones Configurable Speaker Series life safety ceiling speaker strobes are small compact and audible visible emergency signaling devices Protruding more than 1.6 41 mm from the ceiling Genesis speaker blend with any decor safety appliances feature textured housings in architecturally white or eye catching life safety red to patented breakthrough technology Edwards Gen strobes do not require bulky specular reflectors and lenses an exclusive cavity design conditions light to produce a controlled distribution pattern FullLight strobe technology a smooth light distribution pattern without the spikes voids characteristic of specular reflectors This ensures the coverage area receives consistent illumination from the flash on the model Genesis clear lens speaker strobes 15 to 95 or 95 to 177 candela output see ordering infor which is selectable with a conveniently located switch The output setting remains clearly visible even after final instal yet it is locked in place to prevent unauthorized movement installation Features Field configurable no need to remove the device Select 1 or 2 watt operation 15 30 75 95 cd and 95 115 150 177 cd clear strobe lens models available Switch settings remain visible even after the unit is installed Unique low profile design 30 per cent slimmer profile than comparable signals Available with white or red housings Unparalleled performance loud 90 dBA output ensures clear crisp audio Precision timing electronics meet tough synchronizing standards for strobes when used with compatible modules 25 VRMS and 70 VRMS models available all supplied with a DC blocking capacitor for audio circuit supervision Easy to install Fits all standard 4 square electrical boxes with plenty of 18 12 AWG terminals ideal for long runs existing wiring for extra wire no extension ring or trim plate needed Approved for public and private mode applications UL 1971 listed as signaling devices for the hearing impaired UL 1638 listed as protective visual signaling appliances UL 1480 listed as life safety speaker UL ULC listed for ceiling or wall use 1 of 4 D A T A S H E E T S85001 0556 to be used for installation purposes Issue 8 wiring terminals accommodate 18 to 12 AWG 0.75 mm 2.5 mm wiring Application strobes are UL 1971 or 1638 listed for indoor use Prevailing require strobes to be used where ambient noise conditions specified levels where occupants use hearing protection in areas of public accommodation Consult with your Authority Jurisdiction for details Genesis strobes exceed UL synchronization requirements 10 milliseconds over a two hour period when used with a source Synchronization for multiple strobe lights a single field of view is required Application suggested sound pressure level for each signaling zone used alert or alarm signals is a minimum of 15 dB above the aver ambient sound level or 5 dB above the maximum sound level a duration of at least 60 seconds whichever is greater This measured 5 feet 1.5 m above the floor the distance from the signal to the ear will theoretically a 6 dB reduction in the received sound pressure level The effect depends on the acoustic properties of materials in space Doubling the power output of a device e g a speaker 1 W to 2 W will increase the sound pressure level by 3 A 3 dBA difference represents a barely noticeable change in audible visual signals must be installed in accor with guidelines established for strobes dia mm and Mounting models are intended for ceiling or wall applica only Speaker strobes mounted to a flush 4 square box 21 8 54 mm ceiling speaker simply unlatch and down to open This access to mounting screws the selectable candela wattage switches The shallow depth of devices leaves ample room the signal for extra wir Once installed with the cover place no mounting screws are mm mm of Box of ceiling tile speaker strobe Level Output Rated dBA dBA dBA dBA dBA dBA 1 dBA dBA Rated dBA dBA dBA dBA dBA dBA dBA dBA W W W W level output notes dBA Decibels A weighted UL1480 Sound level at 10 ft 3.05 m measured in a reverberant room using 400 to 4,000 Hz band pink noise ULC S541 Meets or exceeds 85 dBA in an anechoic chamber at ft 3.05 m Directional characteristics Within 6 dB of on axis sound level when 90 off axis horizontal Note installed these devices are not on the electrical box Make boxes are mounted to compensate for this difference Use the mount template provided with installation sheet 3100614 switch switch Configuration ceiling speaker may be set for or 2 watt operation De on the model Gen ceiling speaker strobes multi candela output ordering information settings are changed by simply opening the device and the switches to the desired settings The speaker strobe not have to be removed to change the output settings The remain visible through small windows on the front of the after the cover is closed 2 of 4 D A T A S H E E T S85001 0556 to be used for installation purposes Issue 8 Sound Output dBA From Speaker output effective cd of rated output 60 90 100 110 120 1.5m 3.05m at 2 watts setting in anechoic chamber Draw Nameplate Rating and vertical outputs reflect the same pattern of UL versus Nameplate Rating high cd output mod or or or B 95 or A or or or or Light output switch settings for UL 1971 listed are selectable by numeric candela ECS MNS appliances are selectable by B C or D designations Current values are shown in mA Current Current high cd output models or or or B 95 or A cd cd cd cd UV stabilized color impregnated engineered Exceeds 94V 0 UL flammability rating Red and models available mount to North American 4 inch square electrical 2 1 8 54 mm inches deep or 960A 4RF round box No extension ring required Suitable for indoor or ceiling applications terminals polarized inputs for speaker 18 to 12 0.75 mm to 2.5 mm wire size 32 120 F 0 49 C ambient temperature 0 93 humidity ULC S541 year 2004 UL requirements for UL1638 and UL1971 FM MEA CSFM and with UL1480 Fifth Edition All speaker strobes with ADA Code
