Edwards Installation instructions for 5532MD speaker amplifier

Series Adaptatone Speaker Installation Sheet 5532MD Series Adaptatone Speaker Amplifier is a UL and cUL audible signal appliance that is designed to accept system audio levels of 10 VRMS 5532MD 10AW or 70 VRMS making it possible to interface to public address where area wide system audio is required The units are also polarized for use in fire alarm applications the 5532MD Series units are UL and cUL listed for use in hazardous locations shown in Table 1 speaker amplifier is a heavy duty stand alone signaling device operates from local power and sounds a tone programmed at the generator The speaker direction and output level are easily equipment is suitable for use in Class I Division 2 Groups A B and D Class II Division 2 Groups F and G and Class III locations or nonhazardous locations and wire this device in accordance with applicable national and codes ordinances and regulations the signal is used in a fire protective signaling system you must it in accordance with these instructions and with the applicable of NFPA 70 and 72 in the US or CAN ULC S524 and C22.1 in Canada the device is used in general signaling applications you must it in accordance with these instructions and with the applicable of NFPA 70 in the US or CSA C22.1 in Canada the device is used in Division 2 applications you must install it in with the NFPA 70 Article 501 4b Adaptatone can be mounted on any flat surface or can be used as freestanding unit mounted on a rigid pipe The Adaptatone must be by a trained and qualified electrician Explosion hazard Do not disconnect equipment unless power has removed or the area is known to be nonhazardous Explosion hazard Substitution of any components may impair for Class I Division 2 To ensure the integrity of the Adaptatone assembly when adjusting speaker direction make sure threads in the enclosure remain engaged and do not turn speaker more than 360 degrees the original factory installed position To prevent fire shock and component damage no work including board removal should be performed while the circuit is High voltage is present when product is energized High volume may cause harm to personnel in close proximity To ensure the integrity of the enclosure Make sure that the cover P N P 007549 0069 is adhered into the groove at the perimeter before replacing the signal box cover Ensure that the four collar gaskets P N P 041930 0362 are in on each cover screw before securing the signal box cover When securing the cover start the screws by hand making sure they are threaded into the tapped holes in the housing bosses securing them with a screwdriver Torque the signal box screws to a minimum of 20 in lbs This ensures the required fit During installation care must be taken so that components the printed circuit board are not damaged Any kind of service or maintenance performed while unit is will void the warranty The increased resistance due to long wire runs needs to be for in sizing wire Consult Applications Engineering for install the Adaptatone Mount Adaptatone as shown in Figure 1 Surface mounting Secure the unit to the mounting surface the four mounting holes in the mounting plate on the rear of box Use the 10 x 3 wood screws furnished loose or other not supplied suitable for the mounting surface Pipe mounting Loosen the four cover screws from the box and lift off the signal box cover The cover screws are captive Do not remove them from the the center knockout in lower wall of the box and mount box on a 1 2 in conduit pipe using a suitable connector Wire in accordance with the instructions in on page 2 Adjust the volume level if desired by turning the potentiometer on the main board Figure 6 Tightly secure the signal box cover using the four retained cover Torque the signal box cover screws to a minimum of 20 in lbs To adjust the speaker direction the loosen large star nut Figure 1 turn the speaker to the approximate desired position of the speaker direction adjustment it is important that star nut be tightened wrench tight to ensure the speaker is maintained securely Verify operability 2015 UTC Fire Security Americas Corporation Inc 4 3100358 EN REV 03 ISS 16JAN15 1 Mounting the Adaptatone 2 Terminal block TB1 Speaker Large star nut to adjust direction Signal box Cover screws 4X Collar gaskets 4X Mounting plate 10 3 screws or hardware for the mounting Raceway and connections supplied to 1 2 in hole To prevent fire and shock wire the Adaptatone only as in this installation instruction Risk of system failure Electrical supervision requires that the run be broken at each terminal Do not loop the field wires around terminals Terminal Block TB1 can be unplugged from the main board to wiring as shown in Figure 2 wire the Adaptatone wires through a knockout hole in the bottom of the box from raceway that is with its connections to the 1 2 in conduit hole approved for the same degree of protection and type needed by the application Use the plastic cable on the barrier to the electronics to separate incoming power from signal and tone initiating leads per NEC Figure 4 Wire as follows referring to Figure 4 Connect the green and yellow striped earth ground wires to ground See Figure 4 and Figure 5 Connect the audio in and to AUD and terminals respectively on the speaker audio coupler board Use shielded cable and connect braid or drain to the earth ground wire on the unit Connect wires leading to the next signal or end of line resistor TB1 terminals 1 and 2 on the main board as shown in 3 Polarity must be observed Optional Connect an external 24 VDC battery not supplied in with the separate diode assembly P N 2600010 to TB1 terminals 3 and 4 on the main board as in Figure 3 and marked on the diode assembly Terminal block TB1 Main board 3 Wiring to terminal block TB1 To next signal or end of line resistor From control panel signal circuit Diode assembly P N 2600010 To optional 24 VDC battery backup Polarity is shown in the alarm condition The polarity is reversed the field wire monitoring the condition of the control panel 4 Wiring the 5532M series speaker amplifier Audio coupler board Plastic cable ties provided used to separate power leads from and tone initiating leads Signal leads to be connected to the audio coupler board as 24 VDC wiring from the fire alarm control panel FACP 4 3100358 EN REV 03 ISS 16JAN15 5 Wiring audio output of FACP to speaker amplifier audio board AUD Audio AUD Audio Relay Power supervision where applicable Audio coupler board To other speaker amplifier audio coupler boards Tone generator 6 5532M Series PC board locations to Table 2 to Table 2 to Table 3 lb 4.1 kg locations 1 locations Hazardous locations and variable ambient conditions apply only UL Listings are accepted to 151 to 66 to 104 to 40 ambient temp temp 1 Hazardous locations number location I Div 2 A B C D II Div 2 Groups F G III code 160 320 100 212 2 Electrical specifications VDC VDC VDC VDC VFWR 120 Hz VFWR 120 Hz tone on A A A A A A Audio input board Main board Direction of increasing volume Potentiometer for volume adjustment and testing
