Edwards Installation Sheet, Genesis Ceiling Speaker

Product description Genesis Ceiling Speaker is an audible fire alarm appliance designed for indoor ceilings and walls Table 1 for a list of model numbers speaker includes a field configurable switch for selecting desired wattage tap The wattage tap setting is locked in and remains visible after final installation this device in accordance with applicable requirements the latest editions of the NFPA codes and standards and Electrical Code Part 1 Section 32 and in with the local authorities having jurisdiction 1 Models Vrms white Vrms white with marking Vrms white Vrms white with marking Vrms red with FIRE Ceiling Speaker voltage 25 Vrms model S2 70 Vrms model S7 voltage 30 V maximum level output See Table 2 response 400 to 4,000 Hz size 12 to 18 AWG 2.50 to 0.75 sq mm electrical boxes American 4 in square electrical box 2 1 8 in deep listed flush mounted with no extension ring environment 32 to 120 0 to 49 0 to 93 RH noncondensing at 90 32 listings Meets ULC S541 and UL 1480 fifth edition BS EN 60065 2002 Nameplate marking is located the inside surface of the device 2 Sound level output dBA W W W W UL W ULC UL 25V ULC 70V UL 70V ULC Decibels A weighted 1480 Sound level output at 10 ft 3.05 m measured in a room using 400 to 4,000 Hz band limited pink Meets or exceeds 85 dBA in an anechoic chamber 10 ft 3.05 m characteristics Within 6 dB of on axis sound level measured 90 off axis horizontal instructions Electrical supervision requires the wire run to be at each terminal Do not loop the signaling circuit field around the terminals install the speaker Remove the cover by depressing the tab on the side of the with a small screwdriver Turn the cover to release Connect the speaker terminals to the signal circuit field You must observe polarity for the unit to function See Figure 1 Slide the wattage switch to the desired wattage tap 2 W W 1 2 W or 1 4 W by aligning it with the indicator the switch See Figure 2 Sheet Ceiling Speaker P N 3100611 REV 5.0 2 Mount the unit onto a compatible electrical box The switch position must be as shown in Figure 3 Replace the cover by positioning the alignment arrows and rotating the cover clockwise Test the unit for proper operation unit is not serviceable or repairable Should the unit fail to contact the supplier for replacement a visual inspection and an operational test twice a or as directed by the local authority having jurisdiction voltage matching the voltage rating of speaker 25 or 70 Vrms listed alarm 1 Wiring diagram next or of line switch 2 Wattage switch 3 Mounting diagram flush mounted electrical box 3100611 REV 5.0 2 Sheet Ceiling Speaker
