Edwards Installation Sheet, Genesis Ceiling Strobe

Product information Ceiling Strobe voltage 16 to 33 Vdc 16 to 33 Vfwr device was tested to the Regulated 24 Vdc fwr voltage limits of 16 V and 33 V Do not apply and 110 of these values for system operation operating current See Table 3 output Selectable at 15 30 75 and 95 cd Meets UL 1971 requirements Maximum resistance between any two devices is 20 to specifications for the synchronization control this strobe and the control panel to determine wire resistance size 12 to 18 AWG 2.50 to 0.75 sq mm electrical boxes American 4 in square electrical box 2 1 8 in deep extension ring environment 32 to 120 0 to 49 0 to 93 RH noncondensing at 90 32 listings Meets year 2004 UL requirements for UL1638 and UL1971 see Figure 1 and requirements for standards CAN ULC S526 02 CAN ULC S524 01 cd cd 3 Strobe operating current in RMS A cd Volts direct current regulated and filtered Volts full wave rectified currents shown above were measured by UL at 16 and 16 Vfwr cd 10 15 20 of rated output and vertical outputs reflect the same pattern 1 UL 1971 minimum light output of rating vs angle Genesis Ceiling Strobe is a visible fire alarm notification designed for indoor ceilings and walls See Table 1 a list of model numbers strobe includes a field configurable switch for selecting the candela output The candela output setting is locked in and remains visible after final installation strobe features an enhanced synchronization circuit to with the latest requirements of UL 1971 Signaling for the Hearing Impaired and the latest Canadian CAN ULC S526 02 Synchronized operation requires separately installed synchronization control module See 2 for a list of compatible synchronization modules this device in accordance with applicable requirements the latest editions of the NFPA codes and standards and Electrical Code Part 1 Section 32 CAN ULC S524 Standard for the Installation of Fire Alarm Systems and in with the local authorities having jurisdiction 1 Models to 95 multi cd white to 95 multi cd white FIRE marking MGCF VM to 95 multi cd red FIRE marking 2 Compatible synchronization modules Output Signal Master Mount number SIGA MCC1S LG Sheet Ceiling Strobe P N 3100612 REV 3.0 2 Instructions To reduce the risk of shock disconnect all power allow 10 minutes for stored energy to dissipate before Electrical supervision requires the wire run to be at each terminal Do not loop the signaling circuit field around the terminals listed alarm install the strobe 3 Wiring diagram next or of line switch 4 Candela switch Remove the cover by depressing the tab on the side of the with a small screwdriver Turn the cover to release temporal strobe private mode operation is desired cut JP1 See Figure 2 Connect the strobe terminals to the signal circuit field You must observe polarity for the unit to function See Figure 3 Slide the candela switch to the desired candela output 15 75 or 95 cd by aligning it with the indicator below the See Figure 4 Mount the unit onto a compatible electrical box See 5 Replace the cover by positioning the alignment arrows and rotating the cover clockwise Test the unit for proper operation change the to temporal private mode cut jumper JP1 signal output from 1 fps public 2 Strobe setting If the strobe is set to temporal private mode this is no longer UL 1971 listed and FM Approved but is UL listed 5 Mounting diagram unit is not serviceable or repairable Should the unit fail to contact the supplier for replacement a visual inspection and an operational test twice a or as directed by the local authority having jurisdiction 3100612 REV 3.0 2 Sheet Ceiling Strobe
