HORNS SIRENS Small compact design Completely assembled Choice of 9 field selectable tones Complete with mounting bracket 90dB at 10 ft 3.05m Frequency 700 950Hz Rating Continuous Signal MTS Y1 is a durable multi application DC audible signal de for indoor applications requiring on site tone modification signal has nine selectable sound patterns continuous tone warble fast warble low shriek high shriek slow pip fast pip two tone and fast two tone MTS Y1 is designed for mounting using the knockouts in the impact ABS case See illustration below MTS Y1 is designed for indoor applications requiring on site modification knockouts 5mm 1 10 slots for mounting 5mm diameter 11 32 31 32 11 32 31 32 11 32 No DC mA Copyright 2004 Edwards is a registered trademark Klaxon Signals Ltd Fieldstone Court Cheshire CT 06410 h 2 0 3 6 9 9 3 3 0 0 F x 2 0 3 6 9 9 3 1 0 8
