Edwards Operating Instruction Placard for E-FSA Panels

Frame these instructions and mount on the wall next to the control panel Signaling Fire Alarm Control Panel Operating Instructions models E FSA64G E FSA64GD E FSA64R E FSA64RD E FSA250GD E FSA250R E FSA250RD additional information refer to the Edwards Signaling and eFSA250 Technical Reference Manual P N TO ALARM SIGNALS Evacuate the area Notify the proper authorities immediately and state the and location of the emergency Be prepared to provide directions to firefighters when arrive SILENCE ALARM NOTIFICATION SIGNALS Alarm notification signals should not be silenced after all occupants have been evacuated Press Signal Silence Signal Silenced LED turns on and all audible notification turn off New alarm events turn the notification back on Panel programming may delay alarm silence for up to minute may prevent alarm silencing when water flows the sprinkler system and may not turn off visible circuits RETURN THE SYSTEM TO NORMAL AFTER AN OR SUPERVISORY EVENT Make sure all smoke detectors are free from smoke and manual pull stations are reset Press Reset Panel programming may delay panel reset for up to minute after alarm notification circuits turn on INITIATE A FIRE DRILL Press the Menu button Choose Control Enter your password the minimum of a level one is required Choose Drill audible notification circuits turn on This function will not notify the fire department PERFORM A LAMP TEST panel and remote Press Lamp Test PERFORM A REMOTE ANNUNCIATOR LAMP TEST Press and hold the Silence button on the LCRA for five LEDs on remote annunciators will remain on until silence is released TO TROUBLE SIGNALS Silence the panel buzzer the cause of the trouble and notify the service personnel immediately SILENCE THE PANEL BUZZER Press Panel Silence buzzer turns off Any new events turn the buzzer back Trouble conditions not cleared resound the buzzer after predetermined time Trouble conditions may affect the panel s ability provide early detection and indication of a fire Clear conditions immediately TO SUPERVISORY SIGNALS Silence the panel buzzer the cause of the supervisory signal and the authorized service personnel immediately TO MONITOR SIGNALS Silence the panel buzzer the cause of the monitor signal and notify authorized service personnel immediately TEST RECOMMENDATIONS and Testing in the Edwards Signaling and eFSA250 Technical Reference Manual for test and references by NFPA 72 Protected Premises Fire Alarm System Local Auxiliary Fire Alarm System Remote Supervising Station Fire Alarm System Central Station service contact Inspection by 2011 UTC Fire Security All rights reserved 1 3101201 EN REV 2.0 ISS 14APR11
