Edwards Vigilant Remote Booster Power Supplies

Vigilant Catalog cid 88 Power Supplies and Accessories Booster Supplies MIRBPS10A Booster Power Supply MIRBPS is a UL 864 9th Edition list power supply It is a 24 Vdc and supervised that can easily be con to provide additional noti circuits NACs or auxiliary power for Mass Noti Communication MNEC as well as life safety security access control applications MIRBPS contains the circuitry to monitor and charge internal external batteries Its steel enclosure has room for up to two ampere hour batteries For access control only applications MIRBPS can support batteries totaling up to 65 ampere hours an external enclosure The MIRBPS has four Class B convert to two Class A NACs These can be activated in one or two from the MIRBPS unique dual input circuits MIRBPS is available in 6.5 or 10 ampere models Each output has a capacity of three amperes total current draw cannot the unit rating door MIRBPS meets current UL requirements and is listed under following standards CCN 9th ed ition UOXX Fire Alarm Systems ANET UEHX7 AOTX AOTX7 ALVY UEHX7 APAW APAW7 Police Station Connected Burglar Alarm Units and Systems APOU APOU7 Proprietary Burglar Alarm System Units AMCX UOXXC AOTX7 No 205 Station Alarm Unit Units Fire Alarm Canada Burglar Alarm Units and Systems Canada Equipment Canada Alarm Units and Systems Burglar Alarm Units and Systems Control Systems Features Allows for reliable and regulated power to be installed Provides for Genesis and Enhanced Integrity noti ap needed Cost effective system expansion synchronization Supports coded output operation Self restoring overcurrent protection Multiple signal rates Can be cascaded or controlled independently con On board diagnostic LEDs identify wiring or internal faults Standard Edwards keyed lockable steel cabinet with remov and 230 Vac models available Accommodates 18 to 12 AWG wire sizes Optional tamper switch Dual battery charging rates Optional earthquake hardening OSHPD seismic pre approval component Importance Factor 1.5 1 of 4 D A T A S H E E T M85005 0125 to be used for installation purposes Issue 4 View View knockouts 3 4 in conduit cm in cm in cm in cm in cm in cm in cm routing MIRBPS provides additional power and circuits for noti and other 24 Vdc loads It is listed for indoor dry loca and can easily be installed where needed conditions are indicated on the on board diagnostic LEDs the MIRBPS input sense circuit and the trouble relay if While this provides indication to the host system MIRBPS can still be activated upon command A separate AC contact is available on the MIRBPS circuit board which can programmed for trouble or AC Fail There are seven on board LEDs one for each NAC fault one for battery fault one ground fault and one for AC power unique dual input activation circuits of the MIRBPS can be by any voltage from 6 to 45 VDC or to 33 Vdc full wave recti un The input circuit be con to activate 1 4 of the four possible outputs The input circuit can be con to control circuits 3 and 4 outputs are con for auxiliary operation these circuits be con to stay on or automatically deactivate 30 sec after AC power is lost This feature makes these circuits ideal door holder applications The MIRBPS also has a separate 200 24 Vdc output that can be used to power internal activation NACs can be con for a 3 3 3 temporal or continu output California temporal rate outputs are also available on models This makes the MIRBPS ideal for applications re signaling rates that are not available from the main system addition to the internally generated signal rates the MIRBPS also be con to follow the coded signal rate of the main NACs This allows for the seamless expansion of existing MIRBPS enclosure has mounting brackets for up to three modules to the right of the circuit board Speci where needed Edwards MIRBPS Series Booster Power MIRBPS that are interconnected to and supervised by main system The MIRBPS shall function as a stand alone power supply with its own fully supervised battery compli The MIRBPS battery compliment shall be sized to match requirements of the main system The MIRBPS shall be ca of supervising and charging batteries having the capacity of ampere hours for Mass Noti Communica MNEC life safety and security applications and the capacity 65 ampere hours for access control applications MIRBPS shall be capable of installation for a seismic com Importance Factor of 1.5 The MIRBPS shall provide minimum of four independent fully supervised Class B circuits can be con for noti appliance circuits or 24 Vdc power circuits MIRBPS NACs shall be convertible a minimum of two Class A NACs Each MIRBPS output circuit be rated at 3 amperes at 24 Vdc Each output circuit shall provided with automatically restoring overcurrent protection MIRBPS shall be operable from the main system NAC and Edwards Signature Series control modules MIRBPS NACs be con for continuous 3 3 3 temporal or optionally rate Fault conditions on the MIRBPS shall not impede of main system NAC The MIRBPS shall be provided ground fault detection circuitry and a separate AC fail relay Maintain 1 4 inch 6 mm spacing between power limited and nonpower limited or use type FPL FPLR or FPLP cable per NEC Power limited and supervised when not con as auxiliary power Non when con as auxiliary power Source must be power limited Source determines supervision When using larger batteries make sure to position the battery terminals towards door 2 of 4 D A T A S H E E T M85005 0125 to be used for installation purposes Issue 4 Wiring or cascaded booster on a noti appliance circuit NAC end of line resistors are not required to be at the booster terminals This allows multiple to be driven from a single NAC circuit without the for special con Circuit Circuit Alarm Panel next signaling booster or resistor output 1 output 2 output 3 output 4 Power the Booster for Power Fail delay operation CC1 S modules using the sense inputs appliance circuit NAC appliance circuit NAC appliance circuit NAC appliance circuit NAC listed 15 KW listed 15 KW module module 47 K 47 K mA AUX 1 2 47 k listed 15 k listed 15 k module 1 3 mA AUX 1 2 4 in from device Signature out to device in from previous or Signature out to device Booster supports AC Power fail delay three hours via its trouble contact when switch SW2 6 is on All other troubles reported to supervising
