manual is designed for use by Qualified Technical Personnel ONLY Color Annunciator Manual 270104 Rev 1.2 manual consists of 2 individual manuals Installation Operation Maintenance Manual System Configuration Manual LISTING NUMBER 1994 1994 1994 to include software text to include file DBTOOLS utility to include software Include line update to include U L EDWARDS SYSTEMS TECHNOLOGY INC Parkland Drive FL 34243 contents of this manual are proprietary in nature and are intended for distribution to authorized persons companies distributors others for the sole purpose of conducting business associated Edwards Systems Technology Inc The distribution of information within this manual to unauthorized persons shall constitute a of any distributor agreements and may result in the of legal proceedings Operation Maintenance Manual is a trademark of International Business Machines Corporation of Contents Operation Maintenance Manual DESCRIPTION 1 POWER REQUIREMENTS 2 3 NFPA Guidelines 2 UPS Size Calculations 2 HARDWARE SETUP 4 8 All Models of CCA 4 Connection of CCA 1 R 220 Systems 5 Connection of CCA 4 8 R 220 Systems 6 All Models of CCA 8 OPERATION 9 22 System Window 10 Text Window 11 Operating Sequences 12 Function Menus 12 22 TROUBLESHOOTING 23 PREVENTIVE MAINTENANCE 23 SPECIFICATIONS 24 25 APPENDIX 19 Rack Mount Information 26 30 of Figures Tables 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 1 2 3 4 One Line Diagrams 1 Computer Rear View 4 DB 9 Wiring 5 to IOP 3 Wiring 5 to FCOM 232 Wiring 6 DB 25 Wiring 6 to DB25 Breakout Pigtail 7 Main Screen Display 9 Screen Components 11 Command Menu 13 Active Status Report 16 System Command Menu 18 Rack Mount Details 26 Mount Detail 27 Rack Mount Hardware 28 Rack Mount Hardware 29 Installed in Rack Mount Hardware 30 Secondary Power Supply UPS Backup Periods 2 Type Codes 20 Password Levels Privileges 22 Error Messages 23 Notation Conventions this document the following conventions are used to make distinctions between various text It is understood that every line in a source file ends with cid 145 which will be omitted from the unless required for clarity for commands options switches and literal portions of syntax which must appear as shown for filenames variables and placeholders that represent information which must be by the user Italic is also occasionally used for emphasis in text programs user input and screen output are set in courier typewriter face for keys key sequences and acronyms plus indicates a combination of keys i e CTRL E means hold down the CTRL key pressing the E key comma indicates a combination of keys i e ALT F2 means press and release the key then press and release the F2 key brackets indicate required data entry Text of this sort should be entered verbatim brackets indicate items are optional and a vertical bar indicate a choice between two or more items You must select item unless double square brackets surround the item horizontal ellipsis indicates the preceding item or sequence having the same form appear again vertical ellipsis indicates that some portion of the text has been purposely omitted CAPS Computerized Color Annunciator CCA 1 R CCA 1 220 CCA 1 R 220 CCA 4 R CCA 4 220 CCA 4 R 220 CCA 8 R CCA 8 220 CCA 8 R 220 DESCRIPTION CCA Series Computerized Color Annunciator units are user interactive annunciators used with multiplex fire protection signaling systems CCA Series equipment adds emergency text file history logging capability to large systems comprised of one CCA 1 to eight CCA 8 independent or FCC networks as illustrated in Figure 1 The model name suffix indicates the rack mount the model name suffix indicates 220 VAC operating voltage CCA Series annunciators are with a VGA monitor and keyboard for individual interactive system control All multiplex fire signaling system functions may be operated through the CCA system The CCA system individual control and monitoring for each IRC 3 FCC network 1 CCA One Line Diagrams CCA system receives zone status information from the network s and displays text information with zone changes of state Typically information is displayed regarding hazardous materials medical data or operator instructions Each CCA system has the following Capacity to store up to 70,000 message screens on average Each message screen has a format of lines by 80 characters per line 19 640x480 VGA monitor and 101 key keyboard industrial grade computer with a 50 25 MHz 80486 microprocessor 4MB RAM 1.44MB 3.5 disk and 170MB IDE hard drive System Database CCA system database is initially loaded via an
