EST iO64 Intelligent Life Safety System

GE Fire Life Safety Panels GE EST iO64 intelligent life safety system offers the power of intelligent processing in a confi guration that delivers an solution for small to mid sized applications With detection electronic addressing automatic device map optional Ethernet connectivity and a full line of easily confi g option cards and modules this fl exible system offers advanced that benefi t building owners and contractors alike iO64 provides one Class B analog device loop that supports to 64 device addresses and two Class B Notifi cation Applianc e NACs Optional Class A device wiring is available with the of a module life safety system features an attractive design that fi ts with decor Its distinctive doorfront offers a contemporary look that with red or silver fi nishes All LED indicators and its large display remain easy to see at all times iO64 supports a wide range of accessories and related equip including Series intelligent modules detectors and bases remote annunciators cards that expand system capacity and extend system standard with one loop that supports up to 64 intelligent of any type and two Class B NACs Signature Series modules and detectors C for ALarm and Trouble Form A for Supervisory addressing with automatic device mapping Ethernet port for diagnostics programming and variety system reports programmable switches with LEDs and custom labeling Genesis horn silence over two wires and UL 1971 strobe synchronization Class A wiring up to eight serial annunciators LCD LED only and interface use existing wiring for most retrofi t applications remotely or locally maintenance alert reporting and alarm verifi cation by point detector sensitivity x 20 character backlit LCD display Intelligent Safety System Sheet 85005 0131 Issue 1 to be used for installation purposes Page 1 of 8 iO64 life safety system is a powerful intelligent solution for small mid sized buildings Advanced analog technology delivers the ben of flexible system installation while a clean and easy to opera user interface makes panel operation and system maintenance and intuitive smart choice Series electronic addressing eliminates the tedium of dipswitches and automatic device mapping ensures that device resides on the system at its correct location Mean innovative programming features allow the system designer customize powerful built in features to precisely suit the needs of building owner built right in fully programmable front panel switch LED combinations an added measure of flexibility Their slide in labels take the out of custom applications and present a clean finished for retrofits iO64 is particularly well suited to retrofit applications All are made over standard wiring no shielded cable This means that in most situations existing wiring can be to upgrade a legacy control panel to iO Series technology the expense or disruption of rewiring the entire building with a difference NACs are configurable to fully support the advanced signal technology of GE Genesis and Enhanced Integrity notification These devices offer precision synchronization of strobes UL 1971 standards For Genesis devices enabling this feature connected horns to be silenced while strobes on the same circuit continue to flash until the panel is reset remote annunciation annunciation is a strong suit of the iO64 Up to eight an can be installed on a single system Compatible annun include a range of LED and LCD models that provide zone or annunciation as well as common control capabilities iO64 also supports graphic annunciation with optional RA Annunicator interface modules Each interface provides control indicators and 32 LEDS Consult the Ordering section for details complete line of accessories iO64 life safety system is supported by a complete line of detectors modules and related equipment Consult the Information section for details front panel provides easy to use operator as well as all the controls for front programming A large 80 character LCD system status details and program prompts Large tactile buttons are easy to in low light conditions bright multi color LEDs at a glance status buttons Reset Silence arrow arrow arrow arrow a system reset the panel and remote annunciators during active trouble supervisory or alarm event and new event activations mode Silences active notification appliances Signal Silence a second time turns NACs back on a drill confirmation Pressing drill a second time off the drill function Disables or enables dialer set to modem only Disables or enables the alarm relay mode Moves the cursor to the left mode Toggles between programming selections mode Moves the cursor to the right mode Retrieves a programming option sub menu toggles between a programming option selections mode Advances to the previous event mode Moves the cursor up mode Advances to the next event mode Moves the cursor down mode Displays selected event details mode Retrieves a programming option sub or jumps to the Save function in the menu mode Enters the selected data into the system mode Exits the detailed information display mode Exits the current menu level mode Clears the current entry mode Enters the menu mode mode Exits menu mode a space such as a space between words mode Pressing a button once enters the number the button Pressing the button twice enters the value buttons can be programmed to control or enable a device zone or Panel NAC The buttons can be with a slip in insert Sheet 85005 0131 Issue 1 to be used for installation purposes Page of 8 LEDs Operation Options Alarm LED Flashes when there is an active alarm on any loop On steady once acknowledged LED Flashes when there a fault with a circuit or system component or when a is disabled On steady once acknowledged LED Flashes when there is an active superviso event on any loop On steady once acknowledged LED On when the panel has AC power LED Double flashes when there is a dis circuit alarm relay or remote annunciator Fault Yellow LED On steady during an active ground fault LED Flashes when performing an audible test Steady indicates a silent test LED Flashes when there is an active monitor on any loop On steady once acknowledged LED Indicates that detector needs servicing Power keys LED On steady indicates that NAC circuits turned off but the panel is still in alarm LED On steady indicates that the dialer disabled or that the alarm relay is enabled or when the dialer is set to modem only LED Indicates that the panel is in drill LED Indicates that the panel is resetting LED Indicates that the panel has been during an active trouble supervisory or event and indicates that new event activa have been acknowledged LED Indicates the programmed key func is active fail delay resound inhibit after turn on signal start start banner notification or French or Canada Off premise notification of an AC power failure is to 15 hours Delays the off premise notification of AC power failure by the time period selected NACs resound each time a device in the zone into alarm even if they were silenced Inhibits the NACs from turning on again after were silenced when a second device in the zone into alarm Panel reset is operational immediately minute Panel reset is inhibited for one minute Allows immediate silencing of signals fr
