Kidde Edwards Data Sheet K85001-0391 - Horn-Siren Combination

Horn Siren Series series Duotronic signals are 24 Vdc diode polarized duty high decibel signaling appliances for use in fire alarm where a supervised signal is required Colored sage 5520D Series signals will finction as either a horn or siren by an internal tamper proof switch 5520D Horn Siren has no moving parts or contacts to wear It requires no maintenance or lubrication The horn siren oper with very low current consumption and does not require extra on start up The horn predominant frequency is 1.1 KHz horn output is selected the frequency rises and falls from to 3000 Hz every 3 seconds mounted the horn siren switch is tamperproof The horn is for coded applications while the siren is not The 5520D can be made suitable for outdoor weatherproof applications adding the catalog number 349 Backbox Features No moving parts High dB output Suitable for coded signals horn mode only Swivel adjustable mounting Outdoor weatherproof option Diode polarized Low current draw no inrush current Mounts to one gang opening signals signals are ideal for indoor or outdoor applications schools factories commercial occupancies and lumber They can be used where standard bells or horns are not particularly in areas of high noise level The unit will as a Horn or Siren with just the flick of a switch 1 of 2 D A T A S H E E T K85001 0391 to be used for installation purposes Issue 1 Catalog u Strobes Horns Bells ChimesTechnology that saves livesfirealarmresources com Series signals include a universal mounting plate that permits mounting to a single gang 3 3 or 4 inch octagon outlet box or a 4 inch square box It also be installed without a box directly to the wall or ceiling The megaphone may be through 180 horizontally and 90 vertically All wiring is made to colour coded leads attached to a quick disconnect plug When complete the device just plugs in is locked to the mounting plate with a set screw For weatherproof installations use a No 349 back box ordered separately that saves lives us kidde fire fs utc com Kidde com EngineeredSystems is a UTC brand Corporate Park Drive NC 27302 2016 United Technologies Corporation rights reserved Install this device in accordance the supplied installation instructions applicable editions of the NFPA codes standards and the Canadian Electrical Part 1 Section 32 CAN ULC Standard for the Installation of Fire Systems and in accordance with local authorities having jurisdiction These devices will not operate electrical power As fires frequently power interruptions we suggest discuss further safeguards with your protection specialists Operating Voltage Draw Pressure Output Characteristic Characteristic Connections 24 Vdc mA 114 dBA at 10 ft 3m Siren 112 dBA at 10 ft 3m 1.1 KHz Suitable for coded signals and falls 600 to 1300 Hz every three seconds suitable for coded signals wire leads with quick disconnect plug gray enamel ULC FM Information No Combination 24 Vdc Backbox Wt lb 11.5kg 0.2kg 2 of 2 D A T A S H E E T K85001 0391 to be used for installation purposes Issue 1
