Kidde Edwards Data Sheet K85001-0491 - STI Series Stopper

STI Series II unique and patented device helps to prevent false fire alarms restricting legitimate alarms It consists of a tamper proof Lexan polycarbonate shield and frame that fits easily over pull stations When lifted to gain access to the actual it sounds a piercing warning horn Immediate attention is to the pull station and a prankster will run or be caught alarms can still be pulled proven in thousands of applications around the world colleges schools hospitals nursing homes correctional hotels motels and stores Features Fits virtually all pull stations Tested and approved by wide range of fire prevention and test authorities Unconditional lifetime guarantee against breakage and damage molded polycarbonate cover Guards against physical damage to manual pull station Weatherproofing option Optional 9 volt alkaline battery included powered horn Approvals II has been tested and approved or listed by Underwriter Laboratories No 49G2 Underwriter Laboratories of Canada Issue No 13959C Factory Mutual No OG6A2 AY New York City Board of Standards No 947 81 SA State of California approval not required General Service Administration 1 of 4 D A T A S H E E T K85001 0491 to be used for installation purposes Issue 1 Catalog u Power Supplies and AccessoriesTechnology that saves livesfirealarmresources com of Pull Station Accommodated Stopper II can be installed over a flush mounted station up to inches 140mm wide x 6 inches 171mm high However pull station maximum dimensions will decrease as its depth from wall increases e g 3 inch 19mm deep pull station may be 5 inches 140mm wide x 6 inches 152mm high 1 5 8 inch 41mm deep pull station may be 5 inches 127mm wide x 6 inches 152mm high 2 3 8 inch 60mm deep pull station may be 4 inches 102mm wide x 5 inches 146mm high 2 inch 70mm deep pull station may be 3 inches 76mm wide x 5 inches 140mm high If additional depth is needed use the Conduit Spacer Part STI 3100 which adds 2 inches 51mm to the depth Approval II has received patent approval from the United States 4267549 and Canada No 1147828Z Patents for other are pending types of mounting are available means the pull sta is mounted directly on the wall means the pull sta is mounted on an electrical box from the wall Mounted When the pull is mounted on an electrical away from the wall order Part STI 1130 with horn or Part STI 1230 without horn Each longer screws with anchors a 2 inch 51mm conduit spacer No STI 3100 with knockouts and bottom to accommodate the pipe Added Weatherproofing gasket STI 3002 between Il frame and wall A second must be installed behind the for surface mounting conduit gasket STI 3003 may be to seal the conduit pipe GASKET SPACER NOTICE training and instruction must be provided to avoid the pos that persons in the event of a real fire lift the Stopper II cover the horn and think they have set off the fire alarm Explain the purpose of the Stopper II to authorized personnel Show them how it works Instruct them to upon hearing the Stopper II horn check for the presence of a fire and act accordingly by either pulling the fire alarm or shutting off Stopper II by closing the cover Check with your local fire authorities When covering a pull station UL requires stations to be listed for outdoor use 2 of 4 D A T A S H E E T K85001 0491 to be used for installation purposes Issue 1 Information Stopper II with Horn UL ULC Flush Stopper II with Horn UL ULC Surface Stopper II without Horn Flush Stopper II without Horn Surface WeatherStopper flush c w gasket STI 3002 surface c w gaskets STi x2 2 Spacer STI 3100 and conduit kit inch 50mm Spacer Weatherproofing Gasket Weatherproofing Conduit Gasket Insert plate for rough wall mounting for French labelled model Wt kg 0.6 0.6 0.6 0.2 0.1 3 of 4 D A T A S H E E T K85001 0491 to be used for installation purposes Issue 1 that saves lives us kidde fire fs utc com Kidde com EngineeredSystems is a UTC brand Corporate Park Drive NC 27302 2016 United Technologies Corporation rights reserved 4 of 4 D A T A S H E E T K85001 0491 to be used for installation purposes Issue 1
