Kidde Edwards Data Sheet K85003-2761 - Manual Override Relays

Manual Override Series MR600 Series Relays provide SPDT 10 Amp contacts with override capability by means of an ON AUTO OFF switch relay requires a 24 Vac or 24 Vdc power source supplied by controlling system With the switch in the ON position the relay is energized With the switch in the AUTO position the is allowed to operate as signaled by the controlling system the switch in the OFF position the relay cannot be energized relay position contains a high intensity LED which when indicated the relay coil is energized relay circuits may be snapped apart from standard four eight position modules and are also available in the single configuration Features Each relay position contains 10 Amp SPDT contacts Each relay position contains an on auto off switch for manual or external input control 24 Vac or 24 Vdc operation Each relay position contains a red led to indicate relay is energized Track mounting or metal swage spacers available Bussed power between individual relays which permits only power wires per module Snap apart construction single relays may easily be re from large module common power to each relay position is bussed on the wiring board which permits power to be connected only per multi position module devices are ideal for applications where local or remote are required for control of electrical loads They are suit for use with HVAC Temperature Control Fire Alarm Security management and Lighting Control Systems 1 of 2 D A T A S H E E T K85003 2761 to be used for installation purposes Issue 1 Catalog u Power Supplies and AccessoriesTechnology that saves livesfirealarmresources com that saves lives us kidde fire fs utc com Kidde com EngineeredSystems is a UTC brand Corporate Park Drive NC 27302 2016 United Technologies Corporation rights reserved Requirement Contacts Data Temperature Vac or 24 Vdc 15 mA per position Amps 120 Vac 10 Amps 24 Vdc Recognized CSA Approved to 185 50 to 85 Information SPDT relay with LED switch and mounting track SPDT relay with LEDs switches and mounting track SPDT relay with LEDs switches and mounting track SPDT relay with LEDs switches and mounting spacers 2 of 2 D A T A S H E E T K85003 2761 to be used for installation purposes Issue 1
