Farenhyt IPDACT IP Communicator

IIPP FFiirree AAllaarrmm CCoommmmuunniiccaattoorr Listings new Silent Knight IP communicator UL listed for monitoring of Knight fire alarm panels See compatibility table The IP has two supervised inputs and two additional IP Communicator with Up download adds a modem board 2UD that supports upload download over the or a customer Intranet for Silent Knight Addressable These IP Communicators are UL 864 listed for signaling Other Transmission Technologies and comply with NFPA 72 Refer to the IP Communicator Series Installation PN 53109 for more information models connect to the primary and secondary communication of the panel DACT converting the analog signals into digital at the panel for transmission to a compatible Teldat PLUS IP receiver at a central station The panel normally during an alarm supervisory or trouble event sends contact ID formatted analog information out of the ports to the IP Communicator The IP Communicator the data into highly encrypted Ethernet UDP packets for to a compatible receiver at the central station This listing only requires an IP connection No backup analog line is necessary to work with compatible Contact ID DACT equipped panels from Silent Knight the IP Communicators allow faster and more economic digital alarm transmissions improving times and decreasing costs found with traditional analog They offer value added features such as supervised line where a central station can detect any off line alarm within seconds On the central station side a compatible Plus IP receiver from the Teldat Corporation allows integration into existing conventional central station benefit of an IP Communicator is that it is always on the security and supervision of the central station from once every 24 hours for a supervisory test signal once every 30 90 seconds IP Communicator allows a programmer to upload and data between the user PC and either the IFP 100 IFP or addressable FACP The panel and PC can be anywhere the world wide web or within a corporate intranet user computer runs a program called UDPORT exe to the modem signals from or the newer PS TOOLS panel software In UDPORT exe the user enters the main IP of the VisorALARM receiver the UDP port to use and password Instead of using the PC modem this communicates between the IP Communicators modem at panel and the panel own modem While speed is still limited the baud rate of the panel modem panel communications are 100 digital over IP from the remote program PC all the way the remote panel installation This eliminates any dropouts in communications caused by noise or other factors If an should occur during upload or download the panel is able to modem communications immediately and transmit the to the central station Communicator IP Communicator is registered in the Receiver with a unique serial A subscriber number must be entered the subscriber number database field for IP Communicator This same number is into the subscriber telephone number panel to call in PK PLUS or PS TOOLS as calling the panel on a telephone If these match and the master username and are correct full duplex communication permitted to the panel UL 864 Ninth Edition prohibits to a panel without entering a local password Uploading is permitted at any without entering a password Eliminates the cost of two dedicated phone to UL Standard 864 Only the customer shared IP is required Can use newer low cost non analog digital services such as cable or fiber connection supervision to the station from the once a day test signal once every 30 90 seconds 350268 Rev A Honeywell International Inc IP Communicator is compatible with the following Silent panels Communicator Non upload download IFP 50 IFP 100 IFP 1000 IFP 2000 IFP 1000VIP SK5208 5104 IFP 2000VIP IFP 100VIP Communicator with upload download IFP 100 IFP 1000 IFP 2000 IFP 100VIP IFP 1000VIP IFP 2000VIP PLUS IP Receiver FireWatch IP Communicator reports to the VisorALARM IP receiver manufactured by the Teldat Corporation IP receiver can manage up to 3,000 IP Communicator and is compatible with existing central station alarm software VisorALARM IP receiver is based on high availability technology and uses a high performance embedded system for higher reliability and efficiency All IP configuration and operating data is backed up to a card This allows for an immediate equipment within 60 seconds with almost no downtime and information loss The Primary and Secondary receiver provide maximum level of redundancy and both be backed up by additional receivers for the reliability available in the industry Both receivers in real time over the network to keep information and up to date Each VisorALARM Plus Receiver handle up to 20 concurrent TCP IP connections from Users Requires no change to the existing panel configuration The Communicator connect directly to the primary and analog panel telephone ports Fast alarm transmission less than 10 second transmission Works over any type of customer provided Ethernet 10 100 network connection LAN or WAN DSL modem or modem Data transmits over standard contact ID protocol but is with the industry highest level of encryption AES bit Supports both dynamic DHCP or Public and Private Static addressing Supports dual destination IP receiver address for high configurations all signals are sent to a address should the primary become unavailable User programmable UDP ports for flexibility and compati with firewalls and other network security components Supports an optional third maintenance receiver installed at end user facility that permits local alarm monitoring are received simultaneously at both the central and the customer facility A filter can be applied to specific alarm types such as trouble only events Supports upload download using existing familiar tools Two supervised inputs and two outputs RJ45X Ethernet Termination to Program are three ways to configure the IP Communicator Console terminal using the HyperTerminal software found on all Microsoft operating systems Local or remote Telnet session via Ethernet connection Windows based configuration software shipped with IP or downloaded from www silentknight com IP Communicator can be pre programmed The enters all central station information and an auto password This is saved to the unit flash When the IP Communicator is installed at the site connected to the Internet Intranet it registers itself with central station receiver This eliminates the need for a PC the remote site for programming The IP receiver at the station will automatically configure other during registration most installations the only required parameters are Selection of either DHCP or Static IP Destination primary and secondary receiver IP addresses Account identification number CID Port number of these parameters are assigned by the central station Requirements for full details password Panel Requirements following are required for proper installation of the IP 24 VDC non resettable filtered regulated power SK IP 2UD 155 mA in alarm standby 98 mA SK IP 2 136 mA in alarm 93 mA standby Ethernet network connection ITE listed router gateway Although not required to meet NFPA a small UPS is to provide backup power for customer router switch the HP3 300ULX can provide 12 backup power for small 12 volt routers drawing 500 or less for over 24 hours Dynamic or static IP address dynamic addressing requires server present on the local network NOTE DSL and modems typically use dynamic addressing as supplied network providers UDP port for IP communication with the monitoring station p
