FACP GP 10UD WITH DACT AND REMOTE SITE U D Fike GatorPro GP 10UD is a 24 volt ten zone fire alarm control with built in communicator and remote site Upload Download The integral communicator transmits event information troubles supervisories faults etc to a UL listed central station transmission formats allow the GP 10UD to communicate to all central stations smoke detectors smoke detectors programmable Initiating Device Circuits zones zone may be programmed for N O contact devices pull heat Waterflow operation silenceable or nonsilenceable operation Supervisory operation switch for Reset Drill Silence and Acknowledge or latching critical and noncritical process high low temp programmed for process monitoring require a contact for activiation and can be used to monitor Water level Gas detection Open Close built in Class B Style Y Notification Appliance Circuits NACs expandable to four non fire of air flow Notification Appliance Circuits may be programmed Program 5 to 30 minutes Inhibit 60 seconds March Time Temporal California Non Silenceable a strobe circuit can keep flashing after the panel is silenced amps of Notification Appliance power expandable to 6.0 amps meets the critical power requirements for ADA UL 1971 devices built in fully programmable Form A relays expandable to four with two Form C relays Dual line rotary or Touch Tone DACT interfaces to public telephone network leased phone lines are not voltage AC line voltage voltage operation voltmeter measures Notification Appliance Circuit s voltage programmable via built in keypad no costly external programmers necessary with NFPA 72 Local Central Station and Remote Station DACT only not polarity reversal Fire Alarm No D 1.04.01 1 24 volt power S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 816 229 4615 www fike com formats include Ademco Contact ID and 14 others battery charger for up to 60 hours of standby power power limited technology meets UL power limiting requirements Alarm Presignal Timer Alarm Verification Timer and Optional Trouble Reminder walk test with 256 event walk test buffer drill function disable capability software history buffer with time and date stamp stored in permanent memory real time clock calendar SITE UPLOAD DOWNLOAD GP 10UD may be downloaded or uploaded without compromising the system fire protection at the protected premises Download system programming key system information or Download within one minute without affecting normal fire panel functions system status history walk test files AC line NAC 1 2 3 and 4 Resettable Power and Battery Voltages Programming PK 5210UD programming kit which works with most Hayes compatible modems consult factory for listing Multiple security techniques PC board design using Surface Mount Technology SMT modular telephone jacks for connection to RJ31X Modules VAC 50 60 Hz 2.3 amps VAC 50 Hz 1.2 amps suffix Power Wire size minimum 14 AWG 2.0 mm with 600 volt insulation brownout circuitry voltmeter signal LED One line active indicator for each of two phone lines Dual low telephone voltage detect circuitry event codes per each format to 100 transmitted events messages transmissions of 100 events Formats and Ademco Contact ID formats allow complete transaction to be communicated in under five seconds Contact ID PPS 3 1 standard and expanded PPS 4 1 standard and expanded PPS 4 2 standard and expanded and 4 2 Ademco Express Device Circuits zones Sonitrol 10 includes ten programmable Class B Initiating Device Circuits zones Use the CAC 10F Class A converter to convert all Class B IDCs NACs to Class A smoke detectors zone may support two wire smoke detectors Programming options include Normally Open Contact devices pull heat Waterflow silenceable non silenceable operation circuits are power limited and also fully supervised They allow up to 100 ohms of line resistance and allow for use of 12 to AWG 3.1 to 0.78 mm wire standard auto reset operation switch for Reset Drill Silence Acknowledge and Noncritical Process Monitoring standard auto reset Appliance Circuits Style Y Class B 3.0 amps each Use the CAC 10F Class A Converter Module to convert all Class B NACs and to Class A Option module adds two Style Z Class A NACs 1.5 amps each circuits are fully power limited and meet UL power limiting requirements using fuseless technology four wire smoke detector power 500 mA Outputs Non resettable power 500 mA Option module adds two fully programmable Form C relays fully programmable Form A B relays DEVICES EIA 485 PORT EIA 485 Interface Module Provides Sonitrol 10 with EIA 485 output capable of supporting up to 32 compatible devices listed below Series LED type fire annunciators capable of displaying Alarm red and Trouble yellow LEDs for all ten Device Circuits IDCs Series Lamp Driver Module series for use with custom graphic annunciators Remote Form C relay module Provides eight mappable Form C relays driven by EIA 485 for contact by zone two minimum required for contact by zone Each requires ABS 8RF for mounting For more detailed information on Compatible EIA 485 Devices for use with the GP 10UD please refer to the GP AFM AFM X LDM or ACM 8RF data sheets SPECIFICATIONS cabinet is red with a dark blue overlay Knockouts on the top sides and back provide ease of wire entry The cabinet can surface or semi flush mounted and is compact in design 17.11 high x 14.71 wide 43.46 cm high x 37.36 cm wide 16.90 high x 14.50 wide x 4.50 deep 42.93 cm high x 36.83 cm wide x 11.43 cm deep Ring TR 4 R 20.020 high x 17.620 wide 50.85 cm high x 44.75 cm wide LINE INFORMATION Fike P N 27 016 Ten zone 24 volt Fire Alarm Control Communicator includes backbox transformer technical and a frame post operating instruction sheet Fike P N 27 003 120 VAC 100 VA transformer Expands NAC power from 3.0 to 6.0 amps and system power 3.6 amps to 6.6 amps Fike P N 27 019 Notification Appliance Signal Circuit Relay Expander Module Adds two Class A NACs two Form C relays Fike P N 27 018 Class A Converter Module Converts all Class B Initiating Device Circuits zones and Notification Appliance Circuits to Class A Fike P N 27 008 Printer Interface Module Provides an EIA 232 printer output Includes cable DB9F and adapter Fike P N 27 020 Contains PK 5210UD and other programming software for Windows PC comput cable not included Fike P N 27 022 Internal Dress Panel Fike P N 27 015 DACT phone cord 7 feet long two required UL Listed battery backbox Required for batteries over 12 AH Metal enclosure for mounting each ACM 8RF module Fike P N 27 023 Trim ring RECEIVERS COMPATIBLE WITH THE GP 5UD 16 42 1 Knight CP220FB 5 7 9 1 Ademco Express 2 Ademco Express 1 Standard 1800 2300 1 Ex
