Fike Detectors

Protection Systems and Architect Specifications 007 008 009 026 031 Listed Approved Approved Vertical Proof Mount Fike 60 series Thermal Detectors operate on the temperature and rate anticipation principles principles offer the fastest possible response with least probability of a false alarm for a thermal type Thermal detectors are normally open switches automatically reset when the temperature returns normal thermal detectors are available in a 135 57.2 other temperature settings as needed All units are sealed shock and corrosion resistant and proof Units are available for interior weather and explosion proof applications The Interior Detector has a 2 51 mm diameter plastic base terminal screw type connections for field wiring Explosion Proof Detector has a hexagonal wrench bushing with 1 2 15mm conduit threads and is 4 1 4 108mm long Connection to the is accomplished using two or four 6 152mm leads Fike 60 series Thermal Detectors operate within a range of several degrees of their set point eliminates the problem of thermal lag The rate feature allows for a quicker response when rises rapidly The high expansion sensing rapidly expands with the increasing temperature for actuation one to three degrees in advance the detector set point At the same time however it not respond to momentary temperature fluctua below the selected protection level This eliminates alarms SPECIFICATIONS thermal detectors used shall be the Fike 60 series Detectors These detectors shall operate on rate anticipation fixed temperature concept These shall operate without noticeable thermal lag and designed to anticipate and compensate for tempera rate of rise conditions These detectors shall not on any barometric principle to prevent 1 premature of a fast heat rise 2 lagging more than 5 rating with any type of heat rise detectors shall be hermetically sealed shock corrosion resistant and tamper proof They shall reset when the temperature returns to Thermal detectors shall have a setting of 135 or other appropriate temperature and be for interior weatherproof or explosion applica P N Mount Systems Fike Corporation South 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A Telefax 816 229 4615 NO D1023 7 rights reserved 1999 by Fike Corporation 1999 Issue in U S A
