Fike Fire Alarm Bell P 1 58 01

FIRE ALARM BELL Fire Alarm Bells manufactured by Gentex Corporation provide durable dependable operation required for life safety alarm systems bells are low current high decibel notification appliances for use in fire burglary systems or other important signaling applications Fire Alarm Bells are available in 24VDC or 120VAC 6 or 10 housing and can be used for indoor or outdoor applications When used outdoors Fike Box P N 20 123 125 is also required FEATURES SPECIFICATIONS Four Wire 24VDC or 120VAC Operation High dBA Output Available in 6 or 10 Housing Mounts to a Standard 4 Square Electrical Box Listed for outdoor use when used with the 20 123 125 Back Box 18 AWG Wire Leads Available in Red Metal Finish Meets UL 464 Requirements Fire Alarm Bell Americans with Disabilities Act 4.28.3 BFP City of Chicago BS A MEA 285 91 E CSFM NFPA 72 UL 464 MODELS P N P N VDC VDC VAC VAC Draw 10Ft S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 816 229 0314 www fike com Diagrams AND ENGINEERING SPECIFICATIONS audible signal shall be a Gentex Fire Alarm Bell or approved equal and shall be listed by Underwriters Laboratories Inc UL 464 The notification appliance shall also be listed with the California State Fire Marshall CSFM and the Bureau of and Appeals NYC notification appliance shall produce a peak sound output of 95dBA or greater as measured in an anechoic chamber appliance shall be polarized to allow for electrical supervision of the system wiring The unit will mount to a double box or double workbox without the use of an adapter plate The Fire Alarm Bell must be used with the Outdoor Box outdoor applications to meet UL listing requirements Fike Corporation All Rights Reserved No P 1.58.01 May 2004 Specifications are subject to change without notice
