Fike HFC-227EA Agent Storage Containers C 1 01 01

HFC 227EA AGENT STORAGE CONTAINERS Series 70 Clean Agent Containers are used in fire extinguishing systems to the Clean Agent until a fire develops and the agent must be released The Agent is retained in the container by a valve assembly which contains a rupture disc The disc will be ruptured and the Clean Agent released the operation of an actuator by an electric signal that is automatically or controlled The valve is available in three sizes 1 25mm 2 1 2 and 3 80mm The 1 25mm valve is used on the 10 4 20 8 35 60 27 and 100 pound 44 L containers the 2 1 2 65mm valve is used the 125i 51 L and 215i pound 90 L containers the 3 80mm valve is used the 215 87 375 153 650 267 and 1000 pound 423 L containers After a the valve is field reconditioned by simply replacing three components Series 70 Clean Agent Containers have passed extensive testing by Laboratories and Factory Mutual and are used in installations where to 1045 pounds 3.5 to 474 kg of HFC 227ea is required To eliminate the for multiple containers or using more Clean Agent than necessary these can be filled in 1 pound 0.5 kg increments to their maximum container for HFC 227ea Clean Agent Systems is super pressurized with dry to 360 psig 25 bar at 70 F 21 C to provide a quick and effective in 10 seconds or less Series 70 Clean Agent Containers are supplied with a pressure gauge that a quick visual inspection of container pressure Optional items include a Level Indicator and a Low Pressure Supervisory Switch The Liquid Level provides the convenience of determining the container agent weight removing it from its installed location The Low Pressure Supervisory provides constant monitoring of the container internal pressure and can be either normally opened or normally closed In the event of a decrease in internal pressure from 360 psig to 288 psig 24.8 bar to 18.8 bar the Switch normally opened closed contacts will close open This will a supervisory trouble alarm at the system control panel Series 70 Clean Agent Containers are available for installation in the upright or horizontal positions depending upon the user particular needs and the and size container specified The mounting location of the container is quite It can be mounted at the exact point of discharge or at a remote location adding distribution piping from the container to the nozzle system Refer to the Design Installation and Maintenance Manual P N 06 215 operating temperature range is 32 to 130oF 0 to 54.4oC in any If the Clean Agent reaches an internal temperature range of 160 to F 71.1 86.1 it will create a sufficient internal pressure to burst the disc and release the Clean Agent through the piping network 70 Clean Agent Containers UL Listed Ex4623 FM Approved 0Y4AB AF HFC No C 1.01.01 2 S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 816 229 4615 www fike com cont Series 70 Clean Agent Containers are manufactured in strict accordance with of Transportation DOT regulations The Fike Series 70 Clean Agent have successfully passed testing by Factory Mutual and Underwriters Inc Before leaving the factory each container must pass extensive leakage and pressure testing to 1000 psig 69 bar The containers are constructed from steel alloys and painted with a durable baked enamel finish Series 70 Clean Agent Containers are supplied with a mounting bracket that is to provide the most effective and versatile installation for that particular The 10 20 and 35 pound 4 8 and 15 L container brackets employ two U for securing the container to the bracket The 60 pound 27 L container is secured two quick connecting over center handle clamps The 125i and 215i pound 51 and L containers utilize an L shaped bracket for direct wall mounting or with an floor mounting kit can be mounted on a floor in the valve down position The pound 44 L and 215 pound 87 L through 1000 pound 423 L containers are with one or two U shaped mounting brackets depending upon container size mounting to a wall or other secure surface Sizes and Dimensions U S Standard and Metric 15mm 25mm Outlet Level Boss 15mm 80mm Outlet Level Boss 15mm Level Boss 65mm Outlet SIZES DIMENSIONS SIZES DIMENSIONS MODELS AND SPECIFICATIONS AGENT STORAGE CONTAINER DATA U S STANDARD P N SIZE LB VALVE IN EMPTY WT FILL LBS or upright or upright or upright or upright FILL KG or upright or upright or upright or upright AGENT STORAGE CONTAINER DATA METRIC P N SIZE L WT AND ENGINEERING SPECIFICATIONS Clean Agent shall be stored in Fike Series 70 Clean Agent Storage Containers The containers shall be capable of being in one pound 0.5kg increments to their listed maximum capacity The Clean Agent container shall be activated by a from the control panel which is processed by the Agent Release Module This module shall store the power required operate the actuator The valve shall contain a scored non fragmenting rupture disc to provide an immediate total of all the agent HFC 227ea Clean Agent is stored in the container as a liquid having a natural vapor pressure of psig at 77 5 barg at 25 To aid in discharge the container shall be super pressurized to 360 psig at 70 25 bar at with dry nitrogen Agent discharge shall be completed in 10 seconds or less Agent Storage Containers shall be actuated by an electrical signal that is automatically or manually controlled Normal temperature shall be 32 to 130 0 to 54.4 in any installation Agent Storage Containers shall be equipped with a pressure gauge to display internal pressure This gauge shall be an part of the container and color coded for fast referencing of pressure readings A Low Pressure Supervisory Switch be made available as an option A decrease in internal container pressure from 360 psig to 288 psig 24.8 bar to 18.8 shall cause the normally opened closed Supervisory Switch contacts to close open indicating a trouble or supervisory at the control panel Agent Storage Containers shall be fastened to a wall or other secure surface using a mounting bracket that is for the most effective and versatile installation of each container Fike Corporation All Rights Reserved No C 1.01.01 2 March 2005 Specifications are subject to change without notice
