Fike HFC-227EA Container Accessories C 1 03 01

HFC 227EA CONTAINER ACCESSORIES Kit HFC 227ea 1 25mm Valve and 85 024 2 1 2 65mm Valve Series 85 Reload Kits are designed to facilitate field reconditioning of the line of Fike Clean Agent Containers The 1 25mm Reload Kit will the 10 20 35 60 and 100 lb 4 8 15 27 44 liter Fike Containers The 1 2 65mm kit will service the Fike 125i and 215i lb 51 90 liter Generally each kit consists of a rupture disc a gas cartridge actuator actuator housing pressure gauge replacement core for the fill valve O ring a teflon ring Kit HFC 227ea 3 80mm Valve 3 80mm Reload Kit provides field reconditioning of the 215 375 650 1000 lb 87 153 267 423 liter Containers Each kit consists of a 3 80mm disc valve assembly gas cartridge actuator O rings pressure gauge and core for the fill valve Pressure Switch All Containers Over 10 lb 4 liters 10 lb Container Only devices monitor the pressure within the Clean Agent Container Should of Agent or Nitrogen occur the Pressure Switch normal contacts will indicating a low pressure condition Temperature Limits Enclosure Classification NEMA 4 Contact Rating to 120 F 0 48.9 Body Material Weight Pressure Connection Electrical Connection Pressure Setting pole double throw 5 amps resistive 3 amps 30VDC with irridite finish ounces NPT 6mm NPT 15mm psig 20 bar decreasing Kit 1 and 2 1 2 Kit 3 Switch No C 1.03.01 2 S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 816 229 4615 www fike com UL Listed Ex4623 FM Approved 0Y4A8 AF Valve 1 Check Valve 25 mm 2 Check Valve 40 mm 3 Check Valve 80 mm Fike Check Valve prevents agent loss from the open end of a manifold and or system in the event that one or more containers are removed for servicing the system is discharged This applies to all manifold configurations including Systems of carbon steel the Check Valve has a working pressure of 720 psig kPa and has 1 2 or 3 25 50 or 80 mm female NPT threads Length Values 25 mm 2 ft 0.61 m 50 mm 4 ft 1.22 m 80 mm 4 ft 1.22 m CONT Nipple and Coupling 2 1 2 65mm Victaulic Nipple 2 1 2 65mm Victaulic Coupling 3 80mm Victaulic Nipple 3 80mm Victaulic Coupling purpose of the 2 1 2 65 mm and 3 80 mm victaulic nipple and coupling to connect the 2 55 mm or 3 80 mm check valve s and or system piping to 2 1 2 65 mm or 3 80 mm container valve The coupling is rated at 1000 6895 kPa working pressure and contains a Buna N gasket The nipple is Sch pipe has 2 1 2 65 mm or 3 80 mm NPT male thread at one end and a 2 65 mm or 3 80 mm Victaulic groove on the opposite end Valve Nipple and Coupling Fike Corporation All Rights Reserved C 1.03.01 2 March 2005 Specifications are subject to change without notice
