Fike HFC-227EA Instructional Signs C 1 10 01

HFC 227EA INSTRUCTIONAL SIGNS signs must be supplied in order to provide a system in which the of all devices is easy to understand Fike offers several different standard that comply with NFPA and other industry requirements All signs are plastic and backed with a strong adhesive for easy installation Signs are installed at all entrances CAUTION Room Protected By HFC 227ea near any device for which the extra explanation is helpful Custom signs are upon special request Sign Manual Release Station 02 10137 purpose of the System Release Sign is to identify the manual release station the place where the HFC 227ea System can be manually discharged It also the possibility of the manual station being mistaken for a fire alarm The sign is 4 x 2.25 x 1 16 102 x 57 x 1.6mm and is constructed of plastic with white lettering The System Release Sign should normally be under each HFC 227ea manual release station for quick positive Device Activation Do Not Enter Sign 02 10138 purpose of the System Discharge Sign is to explain the presence of an alarm the event of a HFC 227ea System discharge The sign is 9 x 6 x 1 16 229 x x 1.6mm and is constructed of white plastic with black lettering The System Sign is located next to or under an audible or visual alarm outside of protected space entrance s This sign together with the alarm device s will personnel when HFC 227ea agent has discharged and allow them to take actions Not Enter Sign 02 10139 purpose of the Caution Sign is to alert personnel that the room is protected an HFC 227ea System and that all doors should be kept closed in the event of The sign is 10 x 13 x 1 16 254 x 330 x 1.6mm and constructed of plastic with black lettering The Caution Sign should normally be located the entrance door s leading into any room where HFC 227ea protection is provided Device Activation Exit Sign 02 10105 purpose of the System Discharge Sign is to explain the presence of an alarm the event of an HFC 227ea System discharge The sign is 9 x 6 x 1 16 229 152 x 1.6mm and is constructed of white plastic with black lettering The Discharge Sign is located next to or under an audible or visual alarm of the protected space This sign together with the alarm device will alert when HFC 227ea agent has been discharged and allow them to take action Abort Push and Hold Sign 02 10106 purpose of this System Abort Sign is to identify the presence of the HFC System Abort Station The sign is 4 x 2.25 x 1 16 102 x 57 x 1.6mm is constructed of red plastic with white lettering The System Abort Station is to provide a manual means by which the HFC 227ea system actuation may be interrupted The System Abort Sign should be located next to each Abort Station for quick positive identification RELEASE EXTINGUISHING DISCHARGE ALARM ACTIVE NOT ENTER AREA AREA IS PROTECTED BY A EXTINGUISHING SYSTEM NOT ENTER AREA DURING AFTER DISCHARGE DOOR CLOSED AT ALL TIMES EXTINGUISHING ALARM ACTIVE AREA IMMEDIATELY ABORT AND HOLD No C 1.10.01 3 S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 816 229 4615 www fike com Cont Main Reserve Sign 02 10107 purpose of Main Reserve Sign is to identify the presence of the HFC 227ea Switch Station The sign is 4 x 2.25 x 1 16 102 x 57 x 1.6mm is constructed of red plastic with white lettering The Main Reserve Sign be located under the Main Reserve Switch for positive identification A Switch is used with systems that incorporate main and reserve back HFC 227ea Agent storage Pending Sign 02 10268 purpose of the Release Pending Sign is to explain the presence of an alarm in event of an impending HFC 227ea System discharge The sign is 7 x 4.25 x 178 x 108 x 1.6mm and is constructed of red plastic with white lettering Release Pending Sign is located next to an audible or visual alarm inside of the space This sign together with the alarm device will alert personnel of a HFC 227ea Agent discharge and allow them to take appropriate action RESERVE WHEN IS ACTIVE AREA Fike Corporation All Rights Reserved No C 1.10.01 3 March 2005 Specifications are subject to change without notice
