Fike Hochiki Smoke Detector Tester Removal Tool TRT-A100

TRT A100 SMOKE DETECTOR TESTER REMOVAL TOOL HOCHIKI America TRT A100 Smoke Detector Tester Tool enables the user to access test remove reinstall the SIH and SLK series smoke detectors detectors manufactured with a magnetically dual reed switch for sensitivity testing can be tested This meets the requirements of a UL calibrated test without the use of combustion TRT A100 is in compliance with the test requirements in the NFPA 72 Inspection Testing and Chapter 7 Procedure method of sensitivity testing is designed only for America smoke detector models SIH and SLK that contain a label which identities this specific See below DO NOT attempt to use this method sensitivity testing on detectors without this label the testing with detector wired to appropriate circuit or current limited power source and with applied power Abnormal or low power conditions effect sensitivity Always reset the power before test the next unit Place the TRT A100 onto the detector aligning the orange arrow shown on the removal test tool with the tamper resistant set screw on the detector Wait six to eight seconds Detector SHOULD NOT alarm Continued on back LISTINGS Laboratories S1316 Report 284 91 E Vol II FEATURES Combination tester removal Hochiki America smoke detectors with a reed switch either a Hand held or 15 stainless steel pole with easy grip black handle combustion material needed meter batteries or screwdriver required listed outlined requirements in the NFPA 72 Testing and Maintenance Chapter 7 Tester Removal Tool Tool Handle D x 2.4 H durable PVC plastic visible contrast side for test one side removal Color coded for easy visibility Held or Extension Pole extends to 15 steel with grip black handle subject to change without notice America Corporation Village Drive Suite 100 Buena Park CA 90621 2268 714 522 2246 cid 127 Fax 714 522 2268 Support 800 845 6692 or technicalsupport hochiki com continued the detector does alarm when the removal test tool is placed in this position the detector is not within specified limits and may require service Rotate the TRT A100 one half circle 180 Align white arrow shown on tester tool with tamper resistant set Wait six to eight seconds Detector SHOULD alarm and the indicator LED should remain lit detector does not alarm when the TRT A100 is positioned correctly may not within specified sensitivity limits may require service See Technical Bulletin HA 88 November for more information Procedure section explains how to use the HOCHIKI America TRT A100 Tester Removal Tool to remove smoke detectors their bases Flip the TRT A100 so the five small arrows located beneath the white orange arrows are point upward Fit the TRT A100 to the detector and lock into place To remove a detector rotate the TRT A100 to the left counterclockwise To install a detector rotate the TRT A100 to the right clockwise America Corporation cid 127 TRT A100 subject to change without notice
