Fike Micromist Instructional Signs W 1 05 01

Architect and Engineer Specification SIGNS signs must be supplied in order to provide a system in which the function of all devices is easy to understand offers several different signs to comply with NFPA and other industry requirements All signs are durable and backed with a strong adhesive for easy installation Signs are typically installed at all entrances CAUTION Protected By Water Mist and near any device for which the extra explanation is helpful Custom signs are avail upon special request RELEASE SIGN MANUAL STATION MIST RELEASE AND PULL DEVICE ACTIVATION DO NOT SIGN DO NOT ENTER SIGN 02 10264 purpose of the System Release Sign is to identify the release station as the place where the Water Mist can be manually discharged It also minimizes the of the manual station being mistaken for a fire device The sign is 4 x 2.25 x 1 16 102 x 57 x and is constructed of red plastic with white letter The System Release Sign should normally be located each Water Mist manual release station for quick posi identification purpose of the System Discharge Sign is to explain the of an alarm in the event of a Water Mist System The sign is 9 x 6 x 1 16 229 x 152 x 1.6mm is constructed of white plastic with black lettering The Discharge Sign is located next to or under an au or visual alarm outside of the protected space This sign together with the alarm device s alert personnel when water has discharged and allow to take appropriate actions purpose of the Caution Sign is to alert personnel that room is protected by a Water Mist System and that all should be kept closed in the event of fire The sign is x 13 x 1 16 254 x 330 x 1.6mm and constructed of plastic with black lettering The Caution Sign should be located on the entrance door s leading into room where Water Mist protection is being provided S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 Fax 816 229 0314 www fike com 2002 Issue DEVICE ACTIVATION EXIT SIGN 02 10263 purpose of the System Discharge Sign is to explain the of an alarm in the event of a Water Mist System The sign is 9 x 6 x 1 16 229 x 152 x 1.6mm is constructed of white plastic with black lettering The Discharge Sign is located next to or under an au or visual alarm inside of the protected space This sign with the alarm device will alert personnel when has been discharged and allow them to take appro action Fike Corporation All rights reserved No previously 1216 are subject change without notice
