Fike P 1 16 01 Horn Horn Strobe

HORN HORN STROBE Newest Horn Strobe and Horn Appliances are the Series NS Strobe appliances and the Series NH Horn Both the Series NS and are of LOW CURRENT design with ZERO INRUSH The horn provide a Selectable continuous horn tone or temporal pattern 3 tone when constant voltage from a Fire Alarm Control Panel is applied Each tone has two dBA settings to choose from All horn only or horn with strobe may be Synchronized when used in with the Series SM or DSM Sync Module s Additionally the may be silenced while maintaining strobe activation of the Series NS Strobe appliances All of these features are achievable with either Patented 2 Wire Series NS or with the 4 wire Series NS4 NH 20 117 NS 20 118 Listed Approved Series NS Horn Strobe appliances and NH Horn appliances are for maximum performance reliability and cost effectiveness while or exceeding the latest requirements of NFPA 72 National Fire Code ANSI 117.1 American National Standard for Accessible and Buildings and Facilities and UL Standard 1971 Standard for Signaling Devices for The Hearing Impaired and 464 Audible Signal Appliances Series NS Audible Strobe appliances when properly specified and installed in with NFPA ANSI standards can provide the Equivalent Facilitation allowed under ADA Accessibility ADAAG General Section 2.2 by meeting or exceeding the illumination which results from the ADA strobe intensity of 75 candela at 50 feet This is an illumination of 030 lumens per square foot used with the Wheelock Series SM or DSM Sync Modules the continuous horn tone produces a synchronized Code 3 tone mandated by NFPA 72 1993 with an effective date of July This ensures a distinct Code 3 pattern when 2 or more horns are within hearing distance If not synchronized the temporal sound overlap and not be distinctive At the same time the strobes on the circuit may be synchronized This provides the to comply with ADA recommendations concerning photosensitive epilepsy and meet NFPA requirements when 2 or more visual appliances within the field of view All of this plus the ability to silence the horn is achieved using only 2 WIRES NS NH P N P N Module Sync Module No P 1.16.01 1 S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 816 229 4615 www fike com Wall mount only Include Underwriters Laboratories UL 1971 and UL 464 Listings FCC Part 15 European Community CE California State Fire Marshal CSFM New York City MEA and Chicago approvals on all models compliant Meets OSHA 29 Part 1910.165 Current Inrush Selectable tones and dBA levels tone anechoic 90 or 95 dBA reverberant 82 or 88 dBA Code 3 tone anechoic 90 or 95 dBA reverberant 75 or 82 dBA candela wall mounted strobes are listed at 15 candela under UL Standard 1971 and meet 75 candela on axis for ADA guidelines Non Sync and Sync in one synchronization requires the Series SM or DSM Sync Module Matching horn in 12 24V Selectable AND ORDERING INFORMATION Please read these specifications and associated installation instructions carefully before using specifying or this product Failure to comply with any of these instructions cautions and warnings could result in improper installation and or operation of these products in an emergency situation which could result in property and serious injury or death to you and or others Notes are designed to flash at 1 flash per second minimum from 20 31 VDC for 24 VDC models Note that 1996 specifies a flash rate of 1 to 3 flashes per second and ADA guidelines specify a flash rate of 1 to 3 per second candela ratings represent minimum effective Strobe intensity based on UL 1971 NS Horn Strobe products are Listed under UL 1971 for indoor use with a temperature range of 32 F to 0 C to 49 C and maximum humidity of 85 NH horns are Listed under UL 464 for audible signal appliances Sync Modules are rated for 3.0 amperes at 24 VDC DSM Dual Sync Modules are rated for 3.0 amperes per circuit maximum number of interconnected DSM modules is twenty 20 Synchronized Temporal Code 3 Tone is achieved when the horn tone is selected and connected to Series SM or DSM Sync Modules Refer to NS NH installation instructions NS Current Amperes At 2 Audible 20 24 31 VDC Current with Hi dBA Setting dBA 24 volt models NH Horn Current Strobe Only Input 24 volt models Current Horn Only NH Input with Hi dBA VDC VDC VDC VDC VDC VDC 95 dBA 24 volt models VDC VDC VDC Setting 90 dBA 24 volt models VDC VDC VDC Current with Low dBA Setting Current Horn Only NH Input with Low dBA 24 volt models current per actual Wheelock Production Testing 20 24 31 VDC For rated average and peak current across UL listed voltage range for both filtered DC and unfiltered VRMS DIAGRAMS FOR ALL MODELS and NH Appliances Synchronized with Multiple DSM Modules Interconnecting Wiring Maximum of Twenty 20 and NH Appliances Synchronized with DSM Module Dual Class NAC Circuit with No Audible Silence Feature Appliance Synchronized with SM Module Single Class NAC Circuit with Audible Silence Feature APPLIANCE NON SYNCHRONIZED NS NH must be set on continuous horn tone to achieve synchronized temporal code 3 tone Value determined by FACP NAC Circuit s products must be used within their published specifications and must be PROPERLY specified applied operated maintained and operationally tested in accordance with their installation instructions at the time of and at least twice a year or more often and in accordance with local state and federal codes regulations and Specification application installation operation maintenance and testing must be performed by qualified personnel proper operation in accordance with all of the latest National Fire Protection Association NFPA Underwriters UL National Electrical Code NEC Occupational Safety and Health Administration OSHA local state province district federal and other applicable building and fire standards guidelines regulations laws and codes but not limited to all appendices and amendments and the requirements of the local authority having AHJ Contact Wheelock for the current Instructions P83518 and Information P82380 on these products These documentations do undergo periodic changes It is important that you current information on these products These materials contain important information that should be read to specifying or installing these products including Use series NS NH only on circuits with continuously applied operating voltage Do no use series NS NH current required by all devices connected to system primary and secondary power sources ratings on signaling circuits to handle peak currents from all appliances on those circuits flash rate from multiple strobes within a person field of view voltage applied to these products must be within their rated input voltage range of 110 Candela strobe products in sleeping areas in office areas and other specification and installation issues coded or interrupted circuits in which the applied voltage is cycled on and off as the strobe may not to comply with the installation instructions or general information sheets could result in improper application and or operation of these products in an emergency situation which could result property damage and serious injury or death to you and or others Conductor size AWG length and should be taken into consideration prior to design and installation of these products particularly retrofit installations Fike Corporation All Rights Reserved No P 1.16.01 1 August 2005 Specifications are subject to change without notice
