shown with 6 base 60 1029 135 P N 60 1030 190 Listed S4067 Approval 3010873 7270 0410 151 MEA 284 91E Vol IV RATE OF RISE THERMAL DETECTORS 135 fixed temperature rate of rise heat detectors are suited for where high heat output fires are expected or in areas where conditions would not allow use of other detection methods Heat are intended for protection of property Do not rely on heat for life safety protection Where life safety is a concern smoke must also be used A UL listed fire alarm panel must electronically the heat detectors fixed temperature rate of rise heat detectors are suited to detect the presence of slow or fast rising temperatures due to burning The construction of these models incorporate a heat element protected from damage by the built in durable guard These electronic heat detectors incorporate two power alarm for 360 indication of status In standby condition the power LEDs Green In an alarm condition the LEDs latch on Red The electronic detection circuitry performs the same function as a Mechanical Device with Electronic Precision If the heat rise is less than 12 the will not alarm until it reaches its alarm temperature 135 or 190 7.5 If the heat rise is greater than 12 the detector will alarm giving an early warning signal and latching the Red alarm LEDs FEATURES or 190 fixed temperature detectors employ a 12 rate of rise function Listed spacing up to 60 by 60 or 4 wire base compatibility relay bases available Highly stable operation RF Transient protection standby current 35mA nominal built in power alarm LEDs for 360 viewing Electronic Operation LEDs confirm detector status with 63 1024 and 67 1033 detectors and their bases Voltage Voltage Voltage Current Current Current Temperature Rating Case Material 135 7.5 190 7.5 30.0 VDC 33.0 VDC VDC 24 VDC max 24 VDC max 24 VDC to 120 to 49 Contacts max 24 V PC ABS Blend S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 816 229 4615 www fike com No P 1.19.01 2 SPECIFICATIONS heat detectors where ambient temperatures do not exceed 120 shall be the 60 1029 fixed temperature rate heat detector rated at 135 For areas where ambient temperatures exceed 120 but not 160 the 60 1030 temperature rate of rise heat detector rated at 190 shall be used detectors shall be installed in accordance with National Fire Protection Association Standard 72 the spacing by Underwriters Laboratories and in accordance with the rules and regulations set forth by the local authorities jurisdiction Automatic heat detectors shall be Underwriters Laboratories listed BASES 6 Product 430 220 Product 430 220 BASES 4 Product 430 220 Product 430 220 Fike Corporation All Rights Reserved No P 1.19.01 2 September 2005 Specifications are subject to change without notice
