INTELLIGENT DUCT SMOKE DETECTORS Fike Eclipse Series photoelectric air duct smoke detectors manufactured by Sensor are capable of sensing smoke in air velocities from 500 to 4,000 feet minute 2.54 to 20.32 m sec Eclipse Series 63 1056 duct housing can accommodate either the 63 1057 or Intelligent Photoelectric Sensor The twist in twist out heads allow for and easy cleaning or application changes without removing the duct housing Eclipse Series Detector samples air currents passing through a duct and gives performance for shutdown of fans blowers and air conditioning preventing the spread of toxic smoke and fire gases through the area intelligent sensors communicate and are continuously monitored through communication line Detector sensitivity changes caused by dirt temperature humidity are reported to the panel allowing compensation algorithms to the sensor set sensitivity An advance indication at the panel specifies sensor address allowing for selected maintenance to be performed as needed alarm annunciation can be accomplished by using the 02 3868 Remote or the 02 3869 or 02 4998 Remote Test Station Both these devices testing of the detector from a remote location Eclipse Series is designed for simplified installation and easy maintenance Duct smoke detectors have specific limitations SMOKE DETECTORS ARE a substitute for an open area smoke detector a substitute for early warning detection and a replacement for a building regular fire detection system to NFPA 72 and 90A for additional information Air Duct Detector FM Approved UL 268A FEATURES AND SPECIFICATIONS Air velocity rating from 500 to 4000 feet per minute to 20.32 m sec Operates from the control panel communication line Continuous sensitivity monitoring from the panel Intelligent photo isolator or non isolator heads with removal Easy to clean UL recognized field replaceable power boards Transparent cover for convenient visual inspection 3 year warranty Has outputs for remote LED display remote test Requires com line power only Powered outputs for remote LED and remote test and Remote test station and remote annunciator accessories Operating Temperature Range 32o to 120oF 0o to Operating Humidity Range 10 to 93 relative non condensing Duct Air Velocity 500 4000 ft min 2.54 20.32 m s Shipping Weight ED DPR 4lbs 1.8 kg Dimensions 14.5 x 5 x 4 36.7 cm x 12.7 cm x cm Specifications Requirements using no accessories Power Supply Voltage 14 30VDC Maximum Standby Current 360 a max Maximum Alarm Current 7 mA max 24VDC on Alarm Response Time 30 sec Power Up Time 2 sec Self Test Initiation Time 1 sec No P 1.51.01 S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 816 229 0314 www fike com Contact Ratings Each set of Form C Contacts Ratings Voltage Description L R 5ms L R 2ms PF 35 PF 35 PF 35 Coded Coded Coded Coded Coded Coded Current Loads at 24VDC mA mA MODELS mA Max mA Max P N Series intelligent duct smoke housing duct sensor head isolator duct sensor head sampling tube duct widths 1 sampling tube duct widths 2 sampling tube duct widths 4 sampling tube duct widths 8 Eclipse Power Board test station see right test station w key see right LED see right filters cap for metal sampling tube plastic sampling tub Test Station S2522 Test Station key UL S2522 Annunciator S2522 Diagram 63 1056 Duct Smoke Detector Using a UL Listed Control Panel For terminals 9 through 14 normally closed and normally opened relay positions are defined with product in reset condition not in alarm Diagram 63 1056 Duct Smoke Detector Optional 02 3868 Diagram 63 1056 Duct Smoke Detector 02 3869 02 4998 Break tab on 02 3868 for use with 63 1056 AND ENGINEERING SPECIFICATIONS duct smoke detector shall be a Fike Model 63 1056 Intelligent Duct Smoke Detector to be used with compatible panels The duct smoke detector shall be UL listed per UL 268A Standard for Smoke Detectors for Duct specifically for use in air handling systems The detector shall operate in air velocities from 500 to 4000 feet minute The detector housing shall be equipped with an integral mounting base capable of accommodating the 63 1062 detector head It shall be capable of remote testing from the 02 3869 or 02 4998 Remote Test Station The smoke detector housing shall incorporate an airtight smoke chamber in compliance with UL 268A The housing shall capable of mounting to either rectangular or round ducts without adapter brackets An integral filter system shall be to reduce dust and residue effects thereby reducing maintenance and servicing Sampling tubes shall be easily after the housing is mounted to the duct by passing through the duct housing Terminal connections shall be of the and clamp method suitable for 14 18 AWG wiring Fike Corporation All Rights Reserved No P 1.51.01 April 2004 Specifications are subject to change without notice
