Architect and Engineer Specification 20 091 SA 20 125 P 1.10.01 1 top space between it and the finished wall the NATP No Appliance Trimplate may be used It provides an 65 of trim for the Appliance An attractive cover is provided for a clean finished appearance on all mod Series RSSP Multi Candela Strobe Plates are a cost way to retrofit required strobe appliances to bells chimes multitones or speakers and easily mounts standard 4 backboxes or for surface mount use with SBL2 surface backbox Approvals include UL 1971 New York City MEA State Fire Marshall CSFM Factory Mutual and Chicago BFP ADA NFPA ANSI compliant Meets OSHA 29 Part 1910.165 Wall mount models are available with Field Candela Settings of 15 30 75 or 110 cd models or 15 75cd Ceiling mount models are available in 15 30 75 100cd Low current draw with temperature compensation to power consumption and wiring costs Strobes produce 1 flash per second over the regulated range 12 and 24 VDC models with wide New UL using filtered DC or unfiltered VRMS input Wall Mount or Ceiling Mount models Synchronize with Wheelock SM DSM or PS 12 24 8 Supply with Wheelock built in sync protocol ZERO Inrush above Peak Compatible with all Wheelock 2 Wire products Fast installation with IN OUT screw terminals using 12 18 AWG wire patented Series RSS Strobe Appliances and RSSP Strobe Plates have lower current draw and Inrush while maintaining outstanding performance and cost effectiveness These versatile appliances satisfy virtually all requirements for indoor wall or ceiling applications options for wall mount models include 15 75cd or patent pending Multi Candela strobe with field candela settings of 15 30 75 or 110cd Ceiling models are available in 15 30 75 or 100cd intensi models may be synchronized when used in conjunction the Wheelock SM DSM Sync Modules or the PS 12 Power Supply with Wheelock Patented Sync Proto Synchronized strobes can eliminate possible restric on the number of strobes in the field of view Wheelock strobes offer an easy way to comply with ADA concerning photosensitive epilepsy as well meeting the requirements of NFPA 72 1999 Series RSS Strobes employ a Patented Inte Strobe Mounting Plate that can be mounted to a single double gang 4 square 100mm European backboxes the SHBB surface backbox If the flush backbox has side Issue S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 Fax 816 229 0314 www fike com 2002 in Amps the highest value of rated average current to determine the maximum number of strobes and to establish power and wire gauge requirements Use the rated peak current or rated inrush current whichever is higher to fuse requirements Details and Engineers Specifications X 4 X 1 1 2 Backbox X 4 X 1 1 2 Surface Backbox 20 113 Information Strobes are designed to flash at 1 flash per second from across their Listed voltage range All candela ratings represent minimum effective intensity based on UL 1971 Strobe models are UL 1971 Listed for indoor use a temperature range of 32o F to 120o F 0o C to C and maximum humidity of 85 RH Rated input voltage either filtered DC or unfiltered FWR Strobe signals for 24 VDC are UL listed over a voltage range from VDC to 31 VDC visual signals shall be Fike 20 XXX devices They shall UL 1971 Listed for Emergency Devices for the Hearing in all public mode installations Strobe shall pro a flash rate of one flash per second minimum over the voltages of 20 to 31 VDC for 24 volt models visual signals shall incorporate a Xenon flashtube en in a rugged Lexan lens or equivalent with solid state Strobes shall meet UL 1971 and produce a flash of one flash per second minimum over the Listed input range The 15 75 candela strobe series shall be when 15 candela UL 1971 Listing with 75 candela near axis is required Fike Corporation All rights reserved No previously 1105 are subject change without notice
