2 Wire Low Flow Smoke Detector Photoelectric Smoke Detector Low Flow Overview velocity rating from to 4000 feet per minute to 20.32 m sec telescopic sampling tube VDC operation reset button mounting tabs and quick mounting to round rectangular ducts from 1 meters wide models available to clean recognized and sensor boards test station option annunciator option cover for convenient inspection 268A listed warranty System Sensor Innovair DH100LP is a 2 wire photoelectric air duct smoke capable of sensing smoke in air velocities from 100 to 4,000 feet per 0.5 to 20.32 m sec This Innovair features Low Flow technology duct smoke detection throughout a broad range of air environ Many dif to solve HVAC applications occur in low air duct where reliable smoke detection is critical Innovair with Low Flow can detect smoke at air speed velocities of 100 feet per minute or while continuing the same reliable performance to 4,000 feet per minute Innovair family is designed for simpli installation and easy maintenance modular construction allows for easy cleaning and uncomplicated of the UL recognized power and sensor boards Duct smoke detectors have speci limitations SMOKE DETECTORS ARE a substitute for an open area smoke detector a substitute for early warning detection and a replacement for a building regular system to NFPA 72 and 90A for additional duct smoke detector information Speci air duct smoke detector shall be a System Sensor Model DH100LP Series Duct Smoke Detector The detector housing shall UL listed per UL 268A speci for use in air handling systems The detector shall operate at air velocities of 100 feet per to 4000 feet per minute 0.5 to 20.32 m sec It shall be capable of local testing via magnetic switch or remote testing the RTS451KEY Remote Test Station The unit shall be reset by local reset button or RTS451KEY The duct detector hous shall incorporate an airtight smoke chamber in compliance with UL 268A Standard for Smoke Detectors for Duct The housing shall be capable of mounting to either rectangular or round ducts without adapter brackets An inte system shall be included to reduce dust and residue effects on detector and housing thereby reducing maintenance servicing Sampling tubes shall either be plastic or be easily installed after the housing is mounted to the duct by passing the duct housing The enclosure shall meet all applicable NEC and NFPA standards regarding electrical junction boxes connections shall be of the strip and clamp method suitable for 12 AWG wiring Specifications 37 cm Length 14 cm Width 7 cm Depth Weight lbs 1.5 kg Temperature Range to 131 F 0 to 55 C Humidity Range to 93 relative humidity Duct Velocity to 4000 ft min to 20.32 m sec Ratings Voltage VDC Voltage Volts peak to peak Capacitance maximum Ratings VDC minimum VDC maximum maximum Ratings VDC minimum at 10mA VDC maximum at 100mA current must be limited to or less by the control panel used the RA400Z remote lamp within the specified alarm Voltage VDC minimum Time Sec maximum Time Sec maximum wiring diagram for 2 wire duct smoke detectors detectors powered from initiating device circuit Wiring Guide LISTED 2 WIRE PANEL DETECTOR LOOP DH100LP IN OUT DETECTOR LOOP DH100LP IN OUT RESISTOR BY MANUFACTURER OPTIONAL ALARM LED VDC NOM ALARM OPTIONAL ALARM LED VDC NOM ALARM IN OUT IN OUT D OPTIONAL WIRING diagram for RTS451 RTS451KEY Remote Test Station to 2 wire duct smoke detectors In In V Out 6 of the RTS451KEY is not used when to a 2 wire detector The RTS451 does not a terminal 6 Reset Out In In V Out Connection Note note that the magnetic coil supplied with the RTS451 RTS451KEY is not required when these accessories used with the DH100 detectors The functionality of the magnetic coil has been designed into the circuitry of Innovair duct smoke detectors Information Number photoelectric duct smoke detector low flow technology photoelectric detector board 2 wire power board sampling tube duct widths 1 0.3 m sampling tube duct widths 2 0.6 m sampling tube duct widths 4 1.2 m sampling tube duct widths 8 2.4 m telescoping sampling tube end cap for T80 71 00 test station with key lock test station annunciator alarm LED annunciator with piezo alarm test module air filters two per package magnet cap for metal sampling tubes replacement screen sounder add on strobe lens Sensor provides system with a variety of accessories including two remote test stations and several different of visible and audible system annunciation As with our duct detectors all duct smoke detector accessories are UL listed Test Station Key UL S2522 Test Station S2522 Annunciator S2522 Annunciator UL S4011 cannot be directly to 2 wire Innovair must operated independently by panel Sounder UL S3593 with PS24LOW add on strobe smoke lens option cannot be directly wired to 2 wire must be operated independently the panel Sensor Sales and Service Sensor Headquarters Ohio Avenue Charles IL 60174 800 SENSOR2 630 377 6495 x3 Sensor Canada 905.812.0767 905.812.0771 Sensor Europe 44.1403.276500 44.1403.276501 Sensor in China 86.29.524.6253 86.29.524.6259 Sensor in Singapore 65.273.2230 65.273.2610 Sensor Far East 85.22.191.9003 85.22.736.6580 Sensor Australia 613.54.281.142 613.54.281.172 Sensor India 91.124.637.1770 x 2700 91.124.637.3118 2002 System Sensor The company reserves the right to change product speci without notice
