Fire-lite ACS Series Annunciators

ACS Series ACM AEM 32AF ACS Series provides a modular line of products for annun and control of the Fire intelligent and legacy fire control panels The ACS provides arrays of to indicate point status zone status system status and some versions the ability to perform system reset silence and drill These ACS units use a serial interface may be located at distances of up to 6,000 feet 1,828.8 from the panel Alarm Circuit On and Trouble LED per point option or more Alarm only option Touch pad control switch option for remote control of acknowledge reset and drill LEDs may be programmed to display status of indicating or control relays as well as system status condi System Trouble LED indicator On Line Power LED indicator Alarm and trouble resound with flash of new conditions Local sounder for both alarm and trouble conditions with button program options May be powered by 24 VDC from the panel or by remote Efficient switched power converter reduces power con Microprocessor controlled electronics fully supervised Slip in custom labels lettered with standard typewriter or supplies program Plug in terminal blocks for ease of installation and service ACS modules are provided in two basic controller mod each with its expander module The ACM 16ATF pro 16 annunciation and control points per module each a red green or yellow Alarm Circuit On LED a yellow LED and a touch key switch The ACM 32AF provides annunciation points per module each with a red green or Alarm Circuit On LED for annunciating control relays LED indicates ON OFF ACS Series provides arrays of LEDs to indicate point sta and in some versions switches to control the state of out circuits ACS Series annunciator and control subsystems use hardware assemblies which allow the custom configu of the annunciator panel to fit the individual job require backboxes and mounting hardware schemes includ special remote cabinets allow the annunciators to be con and configured with other Fire system B 250 remote annunciation applications the modules are typi mounted in special ABF or ABS boxes between the ACS Series annunciators and the Fire Alarm Control Panel FACP is made through an EIA multi drop loop eliminating the need for costly wiring Four wires are required two for the EIA 485 com twisted shielded pair and two for 24 VDC regu power of ACS Series annunciators into existing systems is accomplished Software may require upgrading field wiring terminations use removable compression type blocks for ease of installation wiring and circuit test ACS Series annunciator and control system provides the system with up to 32 remote serially connected each with a capacity of 69 points to support any FACP or remote power supplies and serial communications the ACS to be located virtually anywhere in the protected alarm and or trouble conditions may be annunciated a per point basis or in a grouped or zone configuration of system operational controls such as Signal Silence Reset and local annunciation controls such as Local and Lamp Test may be accomplished through membrane push switches Line Information The Annunciator Control Module 16ATF con 16 red Alarm and 16 yellow Trouble LEDs 16 momentary 8 1 2011 Page 1 of 4 The Annunciator Flush Box 2F provides for the flush of two annunciator modules Includes a painted trim plate 11 27.94 cm high x 10.625 26.99 cm and adhesive backed annunciator label 9.938 25.24 high x 9.188 23.34 cm wide x 3.75 9.525 cm deep see figure The Annunciator Flush Box 4F provides the remote mounting of one to four annunciator modules are provided for use with 1 2 1.27 cm conduit flush mounted ABF 4F includes a painted metal trim plate 27.94 cm high x 19.375 49.21 cm wide and an annun label 9.938 25.24 cm high x 17.75 45.09 cm wide x 6.35 cm deep switches a System Trouble LED an On Line Power and a local piezo sounder with a silence acknowledge for audible indication of alarm and trouble conditions instructions 8.375 21.27 cm high 4.375 11.11 wide The Annunciator Expander Module 16ATF the ACM 16ATF by 16 system points The AEM is identical in size and in frontal appearance to the Up to three of these expander modules can be by an ACM 16ATF for a maximum of 64 system 8.375 21.27 cm high 4.375 11.11 cm wide The AEM 16ATF cannot be used to expand the ACM 32AF The Annunciator Control Module 32AF contains red Alarm LEDs a System Trouble LED an On Line Power and a local piezo sounder with a Silence Acknowledge for audible indication of alarm and trouble conditions instructions 8.375 21.27 cm high 4.375 11.11 wide The Annunciator Expander Module 32AF the ACM 32AF by 32 system points The AEM 32AF identical in frontal appearance to the ACM 32AF One module can be supported by an ACM 32AF provid a maximum of 64 points 8.375 21.27 cm high 4.375 cm wide The AEM 32AF cannot be used to expand the ACM see figure The Annunciator Surface Box 1F pro for the remote mounting of one annunciator module in a enclosure Knockouts are provided for use with 1.27 cm conduit The annunciator mounts directly to the without a dress plate 8.5 21.59 cm high x 4.5 cm wide x 2 5.08 cm deep The ABS 1F is an attractive surface mount backbox mounting one ACS Series Annunciator 9.938 25.16 cm x 4.625 11.75 cm wide x 2.5 6.35 cm deep The Annunciator Surface Box 2F provides for the mounting of one ACM 16ATF AEM 16ATF combina or one ACM 32AF AEM 32AF combination Knockouts are for use with 1 2 1.27 cm conduit The annunciators directly to the ABS 2F without a dress plate 8.5 21.59 high x 8.92 22.66 cm x 2 5.08 cm deep see figure The Annunciator Flush Box 1F provides the remote mounting of a single annunciator module in a enclosure Knockouts are provided for use with 1 1.27 cm conduit The ABF 1F includes a painted metal plate 11 27.94 cm high x 6.25 15.875 cm wide hardware and an adhesive backed annunciator for the dress plate 9.938 25.24 cm high x 4.625 cm x 2.5 6.35 cm deep 2 of 4 DF 52378 B1 8 1 2011 The ABF 1DF and ABF 2DF are semi backboxes for ACS Series Annunciators The mounts one annunciator module and the ABF 2DF two modules Features an attractive smoked glass with Fire keylock Dimensions ABF 1DF Box only 9.938 25.24 cm high x 11.75 cm wide x 2.5 6.35 cm deep Door 11 cm high x 6 15.24 cm wide x 0.75 1.9 cm deep Dimensions ABF 2DF Box only 9.938 25.24 cm high x 23.34 cm wide x 3.75 9.525 cm deep Door 11 cm high x 10.375 26.35 cm wide x 0.75 1.9 cm Annunciator Blank Module is a two sided dress plate in appearance to the front panels of the ACM 16ATF AEM 16ATF modules on one side and the front panels of ACM 32AF and AEM 32AF modules on the other side The module covers unused module positions in the annunci backbox 8.375 21.27 cm high x 4.375 11.11 cm Annunciator Blank Module is a flat black dress plate covers unused module positions in the annunciator back 8.375 21.27 cm high x 4.375 11.11 cm wide Studs a variety of module mounting options are available Specifications specifications on ACS Series Annunciation and Control contact Fire Listings and Approvals listings and approvals below apply to the ACM AEM and the ACM AEM 32AF In some cases certain mod or applications may not be listed by certain approval or listing may be in process Consult factory for lat listing status UL Listed S2424
